Oil Immersed Induction Variable 650V Contact Voltage Regulator

    Buy cheap Oil Immersed Induction Variable 650V Contact Voltage Regulator from wholesalers

    Buy cheap Oil Immersed Induction Variable 650V Contact Voltage Regulator from wholesalers
    • Buy cheap Oil Immersed Induction Variable 650V Contact Voltage Regulator from wholesalers

    Oil Immersed Induction Variable 650V Contact Voltage Regulator

    Ask Lasest Price
    Brand Name : RISING
    Model Number : TSJA-200kVA
    Certification : ISO CE
    Payment Terms : L/C, L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 SET PER Month
    • Product Details
    • Company Profile

    Oil Immersed Induction Variable 650V Contact Voltage Regulator

    Adjustable 3 phase Oil Immersed Induction Variable Contact Voltage Regulator 380V input & 0~430V 500V 650V


    Product Description

    Inductive regulator Adjustable voltage regulator Introductions

    The adjustable voltage regulator main purpose:
    The adjustable voltage regulator induction voltage regulator can steplessly, smoothly and continuously regulate the output voltage under load conditions.
    Mainly used for motor, electrical testing, electric furnace temperature control, rectifier equipment, generator excitation, etc., are widely used in machinery manufacturing, chemical, textile, communications and other industries.
    RISING oil-immersed pressure regulators adopt a new process of chute, with good waveform, and meet the requirements of IEC standards for electrical test power supply.
    This series of products can smoothly and steplessly adjust the load voltage, and the distortion of the output voltage waveform is small.
    Long life, reliable operation, convenient use, maintenance, low loss, strong overload capacity, with two pressure regulating speeds, it is the ideal adjustable power supply for motors, transformers and other electrical appliances.
    Adjustable voltage regulator Features:
    1 No contact adjustment, long service life;
    2 applies to loads of various natures;
    3 Strong overload ability;
    4 reliable operation, easy to use and maintain.


    Technical Parameters


    Capacity: 50~2000kVA
    Input voltage: 380V
    Output voltage: 0~650V
    Frequency: 50Hz
    Effective: 96%
    Dielectric strength: 2000V/60S<10mA
    Overload capacity: >125%----120min,>150%----60min
    Insulation resistance: >20MΩ
    Environment temperature: -25℃~+40℃
    Relative humidity: <95%
    Temperature rise:< 55℃
    Noise level:< 85dB
