    3200 Multi Dryers Fluting Paper Machine Industrial Paper Mill Machinery

    Ask Lasest Price
    Brand Name : PingAn
    Model Number : 3200mm
    Certification : ISO9001:2008
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 8sets/year
    Delivery Time : 8 month
    • Product Details
    • Company Profile

    3200 Multi Dryers Fluting Paper Machine Industrial Paper Mill Machinery

    3200 one wire multi dryers fluting paper equipment of 60T per day


    Description

    This paper making machine is used to produce high strength fluting paper and fluting paper based on the GSM of 50-170g/m2 . This 3200 one wire multi dryers fluting paper equipment is composed of:

    • wire forming section
    • press section, dryer section
    • paper reeling section
    • base section
    • auxiliary system etc.

    Process flow of the 3200 one wire multi dryers fluting paper equipment

    This paper making machine is suitable to produce fluting paper and high strength fluting paper, which is 3200mm net paper width and paper weight 50-170g/ ㎡. Whole production flow as below:


    Air cushion type headbox→ One wire →Two big jumbo roll press with double felt blind hole →Dryer cylinder group → sizing machine→ Horizontal reeling machine


    Structure of this 3200 one wire multi dryers fluting paper equipment

    Forming sectionAir cushion type headbox
    Press sectionTwo big jumbo roll press
    Dryer section24sets dryer cylinders
    Reeling sectionHorizontal reeling machine

    Main technical parameters

    Output: high trenghth fluting paper and fluting paper. Gammage: 50-170g/m2. Net paper width: 3200mm. Reeling width: 3260mm. Headbox lip width: 3500mm. Designed speed: 300m/min. Dynamic balance speed: 400m/min. Working speed: 180-270m/min. Crawl speed: 25m/min. Gauge: 4300mm. Layout: one floor


    Technology Condition

    Dryness after wire section≥20%
    Dryness before dyer cylinder≥45%
    Final paper dryness≥92%
    Transverse shrinkage (average)2%
    Working hours per day22.5h
    Assess production efficiency97%
    Assess final product rate95%

    Main performance requirements and guarantee

    The equipment configuration of this 3200 one wire multi dryers fluting paper equipment can reach the expected production capacity, and the internal and external performance requirements of the paper machine should be first considered.


    Rubber covered request: Rubber surface guarantee period according to supplier who covered rubber. Will attachment the quality regulation of supplier who covered rubber.


    Wire section dewatering elements: Cover is made of alumina ceramics and base is FRP and requires the thermal expansion coefficient of the base is close to that of the ceramic cover. The box is welded of stainless steel 304 and make special heat treatment.

    • The equipment configuration of 3200 one wire multi dryers fluting paper equipment can reach the expected production capacity, and the internal and external performance requirements of the paper machine should be first considered. This is new machine.
    • Rubber covered request: Rubber surface guarantee period according to supplier who covered rubber. Will attachment the quality regulation of supplier who covered rubber.
    • Roll cylinder dynamic balancing speed: 400m/min
    • Dryer cylinder dynamic balancing speed: 400m/min
    • Reeling roll dynamic balancing speed: 1200 m/min
