    2 Lines Character LCD Module , LCD Character Display Modules 5V For Logic Circuit

    Ask Lasest Price
    Brand Name : OK Smart
    Model Number : OKM1602W
    Price : USD1.1 - 1.99
    Certification : SGS
    Payment Terms : T / T, trade assruance, Western Union, L/C, D/A, D/P, MoneyGram
    Supply Ability : 10000 pieces per month
    Delivery Time : 1- 30 working days
    • Product Details
    • Company Profile

    2 Lines Character LCD Module , LCD Character Display Modules 5V For Logic Circuit

    16 Characters * 2 Lines, Character LCD module, Black Character, Yellow Backlight, 5V For Logic Circuit

    Features

    Display construction16 Characters * 2 Lines
    Display modeTN/STN
    Display typePositive Transflective
    BacklightLED
    Viewing direction6 o'clock
    Operating temperatureIndoor
    Driving voltageSingle power
    Driving method1/16 duty,1/5 bias
    TypeCOB (Chip On Board)
    Number of data line8-bit parallel
    ConnectorPin / ZEBRA

    Key Parameters

    Driver ICKS0066 (compatible with HD44780)
    InterfaceParallel
    BacklightYellow
    Character ColorBlack
    Character SetASCII
    Dimension80 * 36 * 12.5

    Interface

    PIN NO.SYMBOLDESCRIPTIONFUNCTION
    1VSSGround0V (GND)
    2VCCPower Supply For Logic Circuit+5V
    3VEELCD Contrast Adjustment
    4RSInstruction/Data Register SelectionRS = 0 : Instruction Register
    RS = 1 : Data Register
    5R/WRead/Write SelectionR/W = 0 : Register Write
    R/W = 1 : Register Read
    6EEnable Signal
    7DB0Data Input/Output Lines8 BIT: DB0-DB7
    8DB1
    9DB2
    10DB3
    11DB4
    12DB5
    13DB6
    14DB7
    15LED+Supply Voltage For LED++5V
    16LED-Supply Voltage For LED-0V

    Our Mono lcd display

    External Dimension

    LCD1602 external dimension
