Epoxy Resin Cast Zero Sequence Current Transformer , Current Sense Transformer Indoor

    Buy cheap Epoxy Resin Cast Zero Sequence Current Transformer , Current Sense Transformer Indoor from wholesalers

    Buy cheap Epoxy Resin Cast Zero Sequence Current Transformer , Current Sense Transformer Indoor from wholesalers
    • Buy cheap Epoxy Resin Cast Zero Sequence Current Transformer , Current Sense Transformer Indoor from wholesalers

    Epoxy Resin Cast Zero Sequence Current Transformer , Current Sense Transformer Indoor

    Ask Lasest Price
    Brand Name : GFUVE
    Model Number : GFFDN0224-1.7G
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 20000 PCS/MONTH
    Delivery Time : 3-7 days
    • Product Details
    • Company Profile

    Epoxy Resin Cast Zero Sequence Current Transformer , Current Sense Transformer Indoor


    Cast Resin Zero Sequence Current Transformer Indoor


    Introduction


    Current transformers typically consist of a silicon steel ring core wound with many turns of copper wire as shown in the illustration to the right. The conductor carrying the primary current is passed through the ring. The CT's primary, therefore, consists of a single 'turn'. The primary 'winding' may be a permanent part of the current transformer, i.e. a heavy copper bar to carry current through the core. Window-type current transformers (aka zero sequence current transformers, or ZSCT) are also common, which can have circuit cables run through the middle of an opening in the core to provide a single-turn primary winding. To assist accuracy, the primary conductor should be centered in the aperture.


    PARAMETERS


    Technical parameters
    StandardsIEC60044; DL/T 653; JB/T 8970
    Rated load≤150VA
    Rated frequency50Hz or 60Hz
    Cosø0.8 (lag)
    Phase numberSingle
    Rated insulation level12/42/75KV,7.2/32/60KV
    Class of pollutionII
    Mechanical parameters
    MaterialEpoxy resin
    Weight (kg)23
    Operating conditions
    Operating temperature-25°C to +55°C
    Daily average temp<+40°C
    Storage temperature-40°C to +70°C
    Altitude<1000 meters
    ConditionNo existence of severely begrimed, erosive and radioactive gas in the air. Permission of long-term operation under rated current.



    SELECTION GUIDE


    ModelClass CombinationAccuracy class and Rated output
    (VA)
    Discharge Capacity
    (Mvar)
    0.20.513
    GFFDN0224-1.7G/66/√3/0.1/√3/0.1/31530601501.7
    GFFDN0224-1.7G/1010/√3/0.1/√3/0.1/3
    GFFDN0224-1.7G/1111/√3/0.1/√3/0.1/3

    Overall Dimensions
