    LTD104C11U Toshiba Screen 10.4" 800x600 LTD104C11U Display

    Ask Lasest Price
    Brand Name : TOSHIBA
    Certification : Standard Certification
    Model Number : LTD104C11U
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc
    Supply Ability : 5000
    • Product Details
    • Company Profile

    LTD104C11U Toshiba Screen 10.4" 800x600 LTD104C11U Display

    LTD104C11U Toshiba Screen 10.4" 800x600 LTD104C11U Display

    1,LTD104C11U Basic Information

    Panel ModelLTD104C11U
    Panel BrandToshiba Matsushita
    Descritiona-Si TFT-LCD ,10.4 inch, 640×480
    Panel Typea-Si TFT-LCD
    Operating Temperature-10 ~ 65 °C
    Storage Temperature-20 ~ 70 °C

    2, LTD104C11U Mechanical Features

    Dot Resolution640(RGB)×480 (VGA)
    Pixel ConfigurationRGB Vertical Stripe
    Pixel Density76 PPI
    Aspect Ratio4:3 (H:V)
    Form FactorFlat Rectangle Display
    Dot Pitch0.110×0.330 mm (H×V)
    Pixel Pitch0.330×0.330 mm (H×V)
    Weight500g (Typ.)
    SurfaceAntiglare
    Active Area211.2×158.4 mm (H×V)
    Bezel Area214.6×161.8 mm (H×V)
    Outline Dimension238.5×177.5 mm (H×V)
    Outline Depth12.0 (Max.) mm
    Holes & BracketsFace mounting holes (4-Φ3.5) on left, right bezel
    Landscape or PortraitLandscape type
    Touch PanelWithout

    3, LTD104C11U Optical Features

    Display ModeTN, Normally White, Transmissive
    Brightness400 cd/m² (Typ.)
    Contrast Ratio500 : 1 (Typ.) (Transmissive)
    Display Color262K (6-bit)
    Response Time50/50 (Max.)(Tr/Td)
    Viewing Angle70/70/50/70 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction6 o'clock
    White color ChromaticityWx:0.330; Wy:0.340
    Sunlight ReadableN

    4, LTD104C11U Electronics Feature

    Vertical Frequency60Hz
    Reverse ScanYes (U/D, L/R)
    Total Power Consumption6.3W (Typ.)

    5, LTD104C11U Backlight System

    Lamp PositionEdge light type (Top side)
    Lamp TypeCCFL
    Lamp Amount2 pcs
    Lamp ShapeStraight
    Lamp Voltage460V (Typ.)
    Lamp Current3.0/6.0/6.5mA (Min./Typ./Max.)
    Interface TypeConnector
    Lamp Driver BoardNo

    6,LTD104C11U Signal Interface

    Signal CategoryTTL
    Signal ClassCMOS (1 ch, 6-bit)
    Input Voltage for Panel3.3/5.0V (Typ.)(VDD)
    Input Current for Panel225mA (Typ.)(VDD)
    Voltage for Display Signals0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD
    Interface TypeConnector
    Signal InterfaceHRS - DF14H-30P-1.25H, Pitch:1.25 mm, Pin:30 pins

    Detail picture for LTD104C11U Toshiba Screen 10.4" 800x600 LTD104C11U Display
