AUO 14inch B140XTN02.8 LCD Panel

    Buy cheap AUO 14inch B140XTN02.8 LCD Panel from wholesalers

    Buy cheap AUO 14inch B140XTN02.8 LCD Panel from wholesalers
    • Buy cheap AUO 14inch B140XTN02.8 LCD Panel from wholesalers

    AUO 14inch B140XTN02.8 LCD Panel

    Ask Lasest Price
    Brand Name : AUO
    Certification : RoHS Compliant
    Model Number : B140XTN02.8
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    AUO 14inch B140XTN02.8 LCD Panel

    AUO 14inch B140XTN02.8 LCD Panel

    Specification for B140XTN02.8:

    B140XTN02.8 Basic Information

    Panel Model

    B140XTN02.8

    Panel Brand

    AUO

    Descrition

    a-Si TFT-LCD ,14.0 inch, 1366×768

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    B140XTN02.8 Mechanical Features

    Dot Resolution

    1366(RGB)×768 (WXGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    112 PPI

    Aspect Ratio

    16:9 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.0755×0.2265 mm (H×V)

    Pixel Pitch

    0.2265×0.2265 mm (H×V)

    Weight

    270g (Max.)

    Surface

    Antiglare, Hard coating (3H)

    Active Area

    309.399×173.952 mm (H×V)

    Outline Dimension

    320.4×205.1 mm (H×V)

    Outline Depth

    3.0 (Max.) mm

    Shape Style

    Slim (PCBA Flat, Depth ≤3.2mm)

    Holes & Brackets

    Face mounting holes (8 pcs) on up, down slugs

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    B140XTN02.8 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    220 cd/m² (Typ.)

    Contrast Ratio

    400 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Color Gamut

    45% NTSC (CIE1931)

    Response Time

    8 (Typ.)(Tr+Td)

    Viewing Angle

    45/45/20/40 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    6 o'clock

    White color Chromaticity

    Wx:0.313; Wy:0.329

    White Variation

    1.25/1.60 (Max.)(5/13 points)

    Sunlight Readable

    N

    B140XTN02.8 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    Total Power Consumption

    2.9W (Max.)

    B140XTN02.8 Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    Lamp Life Time

    12K(Min.) (Hours)

    Interface Type

    Included in panel signal interface

    Lamp Driver Board

    7.0/12.0/21.0V (Min./Typ./Max.)

    B140XTN02.8 Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (1 ch, 6-bit)

    Input Voltage for Panel

    3.3V (Typ.)

    Input Current for Panel

    230/250mA (Typ./Max.)

    Interface Type

    Connector

    Interface Position

    Signal Interface

    STM - MSAK24025P40, Pitch:0.5 mm, Pin:40 pins
