Giantplus 3.2inch GPM1168B0 LCD Panel

    Buy cheap Giantplus 3.2inch GPM1168B0 LCD Panel from wholesalers

    Buy cheap Giantplus 3.2inch GPM1168B0 LCD Panel from wholesalers
    • Buy cheap Giantplus 3.2inch GPM1168B0 LCD Panel from wholesalers

    Giantplus 3.2inch GPM1168B0 LCD Panel

    Ask Lasest Price
    Brand Name : Giantplus
    Certification : RoHS Compliant
    Model Number : GPM1168B0
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    Giantplus 3.2inch GPM1168B0 LCD Panel

    Giantplus 3.2inch GPM1168B0 LCD Panel

    Specification for GPM1168B0:

    GPM1168B0 Basic Information

    Panel Model

    GPM1168B0

    Panel Brand

    Giantplus

    Descrition

    a-Si TFT-LCD ,3.2 inch, 320×240

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -20 ~ 70 °C

    Storage Temperature

    -30 ~ 80 °C

    GPM1168B0 Mechanical Features

    Dot Resolution

    320(RGB)×240 (QVGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    124 PPI

    Aspect Ratio

    4:3 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.06775×0.20325 mm (H×V)

    Pixel Pitch

    0.20325×0.20325 mm (H×V)

    Active Area

    65.04×48.78 mm (H×V)

    Outline Dimension

    70.36×58.96 mm (H×V)

    Outline Depth

    3.2±0.2 mm

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    GPM1168B0 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    300 cd/m² (Typ.)

    Contrast Ratio

    300 : 1 (Typ.) (Transmissive)

    Display Color

    16.7M (8-bit)

    Color Gamut

    55% NTSC (CIE1931)

    Response Time

    40 (Max.)(Tr+Td)

    Viewing Angle

    65/65/55/60 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    6 o'clock

    White color Chromaticity

    Wx:0.320; Wy:0.310

    Sunlight Readable

    N

    GPM1168B0 Electronics Feature

    Driver IC

    COG Built-in ILI9322

    GPM1168B0 Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    Lamp Amount

    3S2P

    Lamp Shape

    2 strings

    Lamp Voltage

    9/11.1V (Min./Max.)

    Lamp Current

    20mA (Typ.)

    Interface Type

    Included in panel signal interface

    Lamp Driver Board

    No

    GPM1168B0 Signal Interface

    Signal Category

    TTL

    Signal Class

    CMOS (1 ch, 8-bit) + SPI

    Input Voltage for Panel

    3.3/3.3V (Typ.)(VCI/VDD)

    Voltage for Display Signals

    0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD

    Interface Type

    FPC
