    CMO 14.1inch N141I3-L03 LCD Panel

    Ask Lasest Price
    Brand Name : CMO
    Certification : RoHS Compliant
    Model Number : N141I3-L03
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    CMO 14.1inch N141I3-L03 LCD Panel

    CMO 14.1inch N141I3-L03 LCD Panel

    Specification for N141I3-L03:

    N141I3-L03 Basic Information

    Panel Model

    N141I3-L03

    Panel Brand

    CMO

    Descrition

    a-Si TFT-LCD ,14.1 inch, 1280×800

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    N141I3-L03 Mechanical Features

    Dot Resolution

    1280(RGB)×800 (WXGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    107 PPI

    Aspect Ratio

    16:10 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.079×0.237 mm (H×V)

    Pixel Pitch

    0.237×0.237 mm (H×V)

    Weight

    415/430g (Typ.Max.)

    Surface

    Antiglare (Haze 42%), Hard coating (3H)

    Active Area

    303.36×189.6 mm (H×V)

    Bezel Area

    306.76×193.0 mm (H×V)

    Outline Dimension

    319.5×205.5 mm (H×V)

    Outline Depth

    5.2/5.5 (Typ./Max.) mm

    Shape Style

    Wedge (PCBA Bent, Depth ≥5.2mm)

    Holes & Brackets

    Side mounting holes (8-M2) on left, right bezel

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    N141I3-L03 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    200 cd/m² (Typ.)

    Contrast Ratio

    350 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Color Gamut

    44% NTSC (CIE1931)

    Response Time

    3/7 (Typ.)(Tr/Td)

    Viewing Angle

    45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    6 o'clock

    White color Chromaticity

    Wx:0.313; Wy:0.329

    White Variation

    1.40 (Max.)(5 points)

    Sunlight Readable

    N

    N141I3-L03 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    N141I3-L03 Backlight System

    Lamp Position

    Edge light type (Bottom side)

    Lamp Type

    CCFL

    Lamp Amount

    1 pcs

    Lamp Shape

    Straight

    Lamp Life Time

    15K(Min.) (Hours)

    Lamp Voltage

    680±68V

    Lamp Current

    2.0/6.0/6.5mA (Min./Typ./Max.)

    Lamp Operating Frequency

    45/80KHz (Min./Max.)

    Lamps Power Consumption

    4.08W (Typ.)

    Interface Type

    Connector

    Lamp Driver Board

    No

    N141I3-L03 Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (1 ch, 6-bit)

    Input Voltage for Panel

    3.3V (Typ.)

    Input Current for Panel

    320/390mA (Typ./Max.)

    Panel Power Consumption

    3.2W (Typ.)

    Interface Type

    Connector

    Signal Interface

    JAE - FI-XB30SRL-HF11, Pitch:1.0 mm, Pin:30 pins
