    AMPIRE 2.2inch AM-240320J4TZQW-00H LCD Panel

    Ask Lasest Price
    Brand Name : AMPIRE
    Certification : RoHS Compliant
    Model Number : AM-240320J4TZQW-00H
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    AMPIRE 2.2inch AM-240320J4TZQW-00H LCD Panel

    AMPIRE 2.2inch AM-240320J4TZQW-00H LCD Panel

    Specification for AM-240320J4TZQW-00H:

    AM-240320J4TZQW-00H Basic Information

    Panel Model

    AM-240320J4TZQW-00H

    Panel Brand

    AMPIRE

    Descrition

    a-Si TFT-LCD ,2.2 inch, 240×320

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -20 ~ 70 °C

    Storage Temperature

    -30 ~ 80 °C

    AM-240320J4TZQW-00H Mechanical Features

    Dot Resolution

    240(RGB)×320 (QVGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    182 PPI

    Aspect Ratio

    3:4 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.0465×0.1395 mm (H×V)

    Pixel Pitch

    0.1395×0.1395 mm (H×V)

    Weight

    TBD

    Active Area

    33.48×44.64 mm (H×V)

    Bezel Area

    35.08×46.24 mm (H×V)

    Outline Dimension

    40.1×71.9 mm (H×V)

    Outline Depth

    3.65 (Max.) mm

    Touch Panel

    Without

    AM-240320J4TZQW-00H Optical Features

    Display Mode

    MVA, Normally Black, Transmissive

    Brightness

    300 cd/m² (Typ.)

    Contrast Ratio

    400 : 1 (Typ.) (Transmissive)

    Display Color

    65K/262K ()

    Color Gamut

    70% NTSC (CIE1931)

    Response Time

    45 (Typ.)(Tr+Td)

    Viewing Angle

    80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    Symmetry

    White color Chromaticity

    Wx:0.290; Wy:0.310

    Sunlight Readable

    N

    AM-240320J4TZQW-00H Electronics Feature

    Driver IC

    Built-in ST7789S

    AM-240320J4TZQW-00H Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    Lamp Amount

    3S1P

    Lamp Shape

    1 string

    Lamp Voltage

    8.7V (Typ.)

    Lamp Current

    15/20mA (Typ./Max.)

    Interface Type

    Included in panel signal interface

    Lamp Driver Board

    No

    AM-240320J4TZQW-00H Signal Interface

    Signal Category

    CPU/RGB/SPI

    Signal Class

    CPU/RGB/SPI

    Input Voltage for Panel

    2.8V (Typ.)

    Input Current for Panel

    9.8mA (Typ.)

    Interface Type

    FPC
