CMO 22inch A220Z2-001 LCD Panel

    Buy cheap CMO 22inch A220Z2-001 LCD Panel from wholesalers

    Buy cheap CMO 22inch A220Z2-001 LCD Panel from wholesalers
    • Buy cheap CMO 22inch A220Z2-001 LCD Panel from wholesalers

    CMO 22inch A220Z2-001 LCD Panel

    Ask Lasest Price
    Brand Name : CMO
    Certification : RoHS Compliant
    Model Number : A220Z2-001
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    CMO 22inch A220Z2-001 LCD Panel

    CMO 22inch A220Z2-001 LCD Panel

    Specification for A220Z2-001:

    A220Z2-001 Basic Information

    Panel Model

    A220Z2-001

    Panel Brand

    CMO

    Descrition

    a-Si TFT-LCD ,22.0 inch, 1680×1050

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    A220Z2-001 Mechanical Features

    Dot Resolution

    1680(RGB)×1050 (WSXGA+)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    90 PPI

    Aspect Ratio

    16:10 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.094×0.282 mm (H×V)

    Pixel Pitch

    0.282×0.282 mm (H×V)

    Weight

    2.44Kgs (Max.)

    Surface

    Antiglare (Haze 25%), Hard coating (3H)

    Active Area

    473.76×296.1 mm (H×V)

    Outline Dimension

    493.7×320.1 mm (H×V)

    Outline Depth

    16.5±0.5 mm

    Holes & Brackets

    Side mounting holes (4-M3) on left, right bezel

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    A220Z2-001 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    300 cd/m² (Typ.)

    Contrast Ratio

    1000 : 1 (Typ.) (Transmissive)

    Display Color

    16.7M (8-bit)

    Color Gamut

    104% NTSC (CIE1931)

    Response Time

    1.3/3.7 (Typ.)(Tr/Td)

    Viewing Angle

    85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    6 o'clock

    White color Chromaticity

    Wx:0.313; Wy:0.329

    White Variation

    1.30/1.50 (Typ./Max.)(13 points)

    Sunlight Readable

    N

    A220Z2-001 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    A220Z2-001 Backlight System

    Lamp Position

    Edge light type (Top and Bottom)

    Lamp Type

    RGB LED

    Lamp Voltage

    29.0/45.0/45.0V (Typ.)(LED_R/LED_G/LED_B)

    Lamp Current

    25.0/25.0/20.0mA (Typ.)(LED_R/LED_G/LED_B)

    Interface Type

    Connector

    Interface Position

    Lamp Driver Board

    No

    A220Z2-001 Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (2 ch, 8-bit)

    Input Voltage for Panel

    5.0V (Typ.)

    Input Current for Panel

    0.9/1.52A (Typ./Max.)

    Interface Type

    Connector

    Interface Position

    Signal Interface

    STARCONN - 093G30-B0001A, Pitch:1.0 mm, Pin:30 pins
