| Brand Name : | CMO |
| Certification : | RoHS Compliant |
| Model Number : | N154C1-P01 |
| Price : | Pls Contact sales team |
| Delivery Time : | stock |
| Payment Terms : | T/T , Paypal, Western Union Escrow etc. |
| Supply Ability : | 1000 |
Panel Model | N154C1-P01 |
|---|---|
Panel Brand | CMO |
Descrition | a-Si TFT-LCD ,15.4 inch, 1440×900 |
Panel Type | a-Si TFT-LCD |
Operating Temperature | 0 ~ 50 °C |
Storage Temperature | -20 ~ 60 °C |
Dot Resolution | 1440(RGB)×900 (WXGA+) |
|---|---|
Pixel Configuration | RGB Vertical Stripe |
Pixel Density | 110 PPI |
Aspect Ratio | 16:10 (H:V) |
Form Factor | Flat Rectangle Display |
Dot Pitch | 0.07675×0.23025 mm (H×V) |
Pixel Pitch | 0.23025×0.23025 mm (H×V) |
Weight | 245/255g (Typ./Max.) |
Surface | Antiglare, Hard coating (3H) |
Active Area | 331.56×207.225 mm (H×V) |
Outline Dimension | 339.2×214.2 mm (H×V) |
Outline Depth | 1.54 (Typ.) mm |
Landscape or Portrait | Landscape type |
Touch Panel | Without |
Display Mode | TN, Normally White, Transmissive |
|---|---|
Brightness | 0 cd/m² |
Contrast Ratio | 400 : 1 (Typ.) (Transmissive) |
Display Color | 262K (6-bit) |
Response Time | 8/23 (Typ.)(Tr/Td) |
Viewing Angle | 65/65/50/60 (Typ.)(CR≥10) (L/R/U/D) |
White color Chromaticity | Wx:0.317; Wy:0.370 |
White Variation | 1.25/1.40 (Typ./Max.)(5 points) |
Transmissivity | 8.9% (Typ.)(with Polarizer) |
Sunlight Readable | N |
Vertical Frequency | 60Hz |
|---|---|
Reverse Scan | No |
Lamp Type | No B/L |
|---|
Signal Category | LVDS |
|---|---|
Signal Class | LVDS (2 ch, 6-bit) |
Input Voltage for Panel | 3.3V (Typ.) |
Input Current for Panel | 430/500mA (Typ./Max.) |
Interface Type | Connector |
Signal Interface | JAE - FI-XB30SRL-HF11, Pitch:1.0 mm, Pin:30 pins |
