CPT 2inch CLAF020FA01AA LCD Panel

    Buy cheap CPT 2inch CLAF020FA01AA LCD Panel from wholesalers

    Buy cheap CPT 2inch CLAF020FA01AA LCD Panel from wholesalers
    • Buy cheap CPT 2inch CLAF020FA01AA LCD Panel from wholesalers

    CPT 2inch CLAF020FA01AA LCD Panel

    Ask Lasest Price
    Brand Name : CPT
    Certification : RoHS Compliant
    Model Number : CLAF020FA01AA
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    CPT 2inch CLAF020FA01AA LCD Panel

    CPT 2inch CLAF020FA01AA LCD Panel

    Specification for CLAF020FA01AA:

    CLAF020FA01AA Basic Information

    Panel Model

    CLAF020FA01AA

    Panel Brand

    CPT

    Descrition

    a-Si TFT-LCD ,2.0 inch, 176×220

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -20 ~ 70 °C

    Storage Temperature

    -30 ~ 80 °C

    Remarks

    full cell

    CLAF020FA01AA Mechanical Features

    Dot Resolution

    176(RGB)×220 (QCIF+)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    141 PPI

    Aspect Ratio

    4:5 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.060×0.180 mm (H×V)

    Pixel Pitch

    0.180×0.180 mm (H×V)

    Weight

    4.1g

    Surface

    Without Polarizer

    Active Area

    31.68×39.6 mm (H×V)

    Outline Dimension

    35.48×48.68 mm (H×V)

    Outline Depth

    1.0±0.1 mm

    Landscape or Portrait

    Portrait type

    Touch Panel

    Without

    CLAF020FA01AA Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    0 cd/m²

    Contrast Ratio

    250 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Color Gamut

    58% NTSC (CIE1931)

    Response Time

    10/20 (Typ.)(Tr/Td)

    Viewing Angle

    45/45/40/20 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    12 o'clock

    Transmissivity

    6.3% (Typ.)(with Polarizer)

    Sunlight Readable

    N

    CLAF020FA01AA Electronics Feature

    Driver IC

    Suggest SPFD54216A

    CLAF020FA01AA Backlight System

    Lamp Type

    No B/L
