CMO 2.5inch F02505-01U LCD Panel

    Buy cheap CMO 2.5inch F02505-01U LCD Panel from wholesalers

    Buy cheap CMO 2.5inch F02505-01U LCD Panel from wholesalers
    • Buy cheap CMO 2.5inch F02505-01U LCD Panel from wholesalers

    CMO 2.5inch F02505-01U LCD Panel

    Ask Lasest Price
    Brand Name : CMO
    Certification : RoHS Compliant
    Model Number : F02505-01U
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    CMO 2.5inch F02505-01U LCD Panel

    CMO 2.5inch F02505-01U LCD Panel

    Specification for F02505-01U:

    F02505-01U Basic Information

    Panel Model

    F02505-01U

    Panel Brand

    CMO

    Descrition

    a-Si TFT-LCD ,2.5 inch, 320×240

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -20 ~ 70 °C

    Storage Temperature

    -30 ~ 80 °C

    F02505-01U Mechanical Features

    Dot Resolution

    320(RGB)×240 (QVGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    159 PPI

    Aspect Ratio

    4:3 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.053×0.159 mm (H×V)

    Pixel Pitch

    0.159×0.159 mm (H×V)

    Surface

    Without Polarizer

    Active Area

    50.88×38.16 mm (H×V)

    Outline Dimension

    55.9×46.76 mm (H×V)

    Outline Depth

    1.0±0.1 mm

    Landscape or Portrait

    Landscape type

    F02505-01U Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    0 cd/m²

    Contrast Ratio

    250 : 1 (Typ.) (Transmissive)

    Response Time

    15/35 (Typ.)(Tr/Td)

    Viewing Angle

    45/45/35/15 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    12 o'clock

    White color Chromaticity

    Wx:0.309; Wy:0.350

    Transmissivity

    6.9% (Typ.)(with Polarizer)

    Sunlight Readable

    N

    F02505-01U Backlight System

    Lamp Type

    No B/L
