AUO 2.2inch H220QT02 V1 CELL LCD Panel

    Buy cheap AUO 2.2inch H220QT02 V1 CELL LCD Panel from wholesalers

    Buy cheap AUO 2.2inch H220QT02 V1 CELL LCD Panel from wholesalers
    • Buy cheap AUO 2.2inch H220QT02 V1 CELL LCD Panel from wholesalers

    AUO 2.2inch H220QT02 V1 CELL LCD Panel

    Ask Lasest Price
    Brand Name : AUO
    Certification : RoHS Compliant
    Model Number : H220QT02 V1 CELL
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    AUO 2.2inch H220QT02 V1 CELL LCD Panel

    AUO 2.2inch H220QT02 V1 CELL LCD Panel

    Specification for H220QT02 V1 CELL:

    H220QT02 V1 CELL Basic Information

    Panel Model

    H220QT02 V1 CELL

    Panel Brand

    AUO

    Descrition

    LTPS TFT-LCD ,2.2 inch, 240×320

    Panel Type

    LTPS TFT-LCD

    Operating Temperature

    -15 ~ 70 °C

    Storage Temperature

    -40 ~ 85 °C

    H220QT02 V1 CELL Mechanical Features

    Dot Resolution

    240(RGB)×320 (QVGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    182 PPI

    Aspect Ratio

    3:4 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.0465×0.1395 mm (H×V)

    Pixel Pitch

    0.1395×0.1395 mm (H×V)

    Weight

    2.8g (Typ.)

    Active Area

    33.48×44.64 mm (H×V)

    Outline Dimension

    37.48×53.14 mm (H×V)

    Outline Depth

    0.6 (Typ.) mm

    Landscape or Portrait

    Portrait type

    Touch Panel

    Without

    H220QT02 V1 CELL Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    0 cd/m²

    Contrast Ratio

    450 : 1 (Typ.) (Transmissive)

    Display Color

    16.7M ()

    Color Gamut

    80% NTSC (CIE1931)

    Response Time

    10/20 (Typ.)(Tr/Td)

    Viewing Angle

    80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)

    Transmissivity

    4.1% (Typ.)(with Polarizer)

    Sunlight Readable

    N

    H220QT02 V1 CELL Backlight System

    Lamp Type

    No B/L

    H220QT02 V1 CELL Signal Interface

    Signal Category

    CPU

    Signal Class

    CPU

    Input Voltage for Panel

    1.8/2.75V (Typ.)(VDDIO/VDD)
