8-Bit CMOS Single-Chip Microcontroller
Description:
The SAB 80C515/80C535 is a powerful member of the Siemens SAB 8051
family of 8-bit microcontrollers. It is designed in Siemens ACMOS
technology and is functionally compatible with the SAB 80515/80535
devices designed in MYMOS technology.
The SAB 80C515/80C535 is a stand-alone, high-performance
single-chip microcontroller based on the SAB 8051/80C51
architecture. While maintaining all the SAB 80C51 operating
characteristics, the SAB 80C515/80C535 incorporates several
enhancements which significantly increase design flexibility and
overall system performance.
In addition, the low-power properties of Siemens ACMOS technology
allow applications where power consumption and dissipation are
critical. Furthermore, the SAB 80C515/80C535 has two
software-selectable modes of reduced activity for further power
reduction: idle and powerdown mode.
The SAB 80C535 is identical with the SAB 80C515 except that it
lacks the on-chip program memory. The SAB 80C515/80C535 is supplied
in a 68-pin plastic leaded chip carrier package (P-LCC-68) or in a
plastic metric quad flat package (P-MQFP-80).
There are versions for 12, 16 and 20 MHz operation and for 16 MHz
operation and for extended temperature ranges – 40 to 85 ˚C.
Versions for extended temperature range – 40 to + 110 ˚C are
available on request.
Applications:
● 8 K × 8 ROM (SAB 80C515 only)
● Boolean processor
● 256 × 8 RAM
● Most instructions execute in 1 µs (750 ns)
● Six 8-bit I/O ports, one input port for digital or analog input
● 4 µs (3 µs) multiply and divide
● External memory expandable up to
● Three 16-bit timer/counters 128 Kbytes
● Highly flexible reload, capture, compare capabilities
● Backwardly compatible with SAB 8051
● Functionally compatible with SAB 80515
● Full-duplex serial channel
● Idle and power-down mode
● Twelve interrupt vectors, four priority
● Plastic leaded chip carrier package: levels P-LCC-68
● 8-bit A/D converter with 8 multiplexed reference voltages
● Plastic Metric Quad Flat Package inputs and programmable internal
P-MQFP-80
● Two temperature ranges available:
● 16-bit watchdog timer 0 to 70 ˚C (for 12, 16, 20 MHz)
– 40 to 85 ˚C (for 12, 16 MHz)
Specifications:
part no. | SAB80C52-16-N |
Manufacturer | SIEMENS |
supply ability | 10000 |
datecode | 10+ |
package | PLCC-44 |
remark | new and original stock |
