AMPIRE 5.7inch AM-640480G2TNQW-TU0H LCD Panel

    Buy cheap AMPIRE 5.7inch AM-640480G2TNQW-TU0H LCD Panel from wholesalers

    Buy cheap AMPIRE 5.7inch AM-640480G2TNQW-TU0H LCD Panel from wholesalers
    • Buy cheap AMPIRE 5.7inch AM-640480G2TNQW-TU0H LCD Panel from wholesalers

    AMPIRE 5.7inch AM-640480G2TNQW-TU0H LCD Panel

    Ask Lasest Price
    Brand Name : AMPIRE
    Certification : RoHS Compliant
    Model Number : AM-640480G2TNQW-TU0H
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    AMPIRE 5.7inch AM-640480G2TNQW-TU0H LCD Panel

    AMPIRE 5.7inch AM-640480G2TNQW-TU0H LCD Panel

    Specification for AM-640480G2TNQW-TU0H:

    AM-640480G2TNQW-TU0H Basic Information

    Panel Model

    AM-640480G2TNQW-TU0H

    Panel Brand

    AMPIRE

    Descrition

    a-Si TFT-LCD ,5.7 inch, 640×480

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -20 ~ 70 °C

    Storage Temperature

    -30 ~ 80 °C

    AM-640480G2TNQW-TU0H Mechanical Features

    Dot Resolution

    640(RGB)×480 (VGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    139 PPI

    Aspect Ratio

    4:3 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.0605×0.1815 mm (H×V)

    Pixel Pitch

    0.1815×0.1815 mm (H×V)

    Surface

    Antiglare, Hard coating (3H)

    Active Area

    116.16×87.12 mm (H×V)

    Bezel Area

    118.02×89.2 mm (H×V)

    Outline Dimension

    140×109.5 mm (H×V)

    Outline Depth

    14.0/22.3 (Typ./Max) mm

    Holes & Brackets

    Face mounting holes (6-Φ3.2) on left, right bezel

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    AM-640480G2TNQW-TU0H Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    500 cd/m² (Typ.)

    Contrast Ratio

    250 : 1 (Typ.) (Transmissive)

    Display Color

    65K ()

    Response Time

    50 (Max.)(Tr+Td)

    Viewing Angle

    70/70/50/50 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    12 o'clock

    White color Chromaticity

    Wx:0.346; Wy:0.378

    White Variation

    1.33/1.43 (Typ./Max.)(9 points)

    Sunlight Readable

    N

    AM-640480G2TNQW-TU0H Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    Interface Type

    Included in panel signal interface

    Lamp Driver Board

    Embedded (LED Driver)

    AM-640480G2TNQW-TU0H Signal Interface

    Signal Category

    UART

    Signal Class

    UART

    Input Voltage for Panel

    4.6/26V (Min./Max.)

    Interface Type

    Connector
