Giantplus 3.2inch GPM745B0 LCD Panel

    Buy cheap Giantplus 3.2inch GPM745B0 LCD Panel from wholesalers

    Buy cheap Giantplus 3.2inch GPM745B0 LCD Panel from wholesalers
    • Buy cheap Giantplus 3.2inch GPM745B0 LCD Panel from wholesalers

    Giantplus 3.2inch GPM745B0 LCD Panel

    Ask Lasest Price
    Brand Name : Giantplus
    Certification : RoHS Compliant
    Model Number : GPM745B0
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    Giantplus 3.2inch GPM745B0 LCD Panel

    Giantplus 3.2inch GPM745B0 LCD Panel

    Specification for GPM745B0:

    GPM745B0 Basic Information

    Panel Model

    GPM745B0

    Panel Brand

    Giantplus

    Descrition

    a-Si TFT-LCD ,3.2 inch, 240×320

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -20 ~ 70 °C

    Storage Temperature

    -30 ~ 80 °C

    Remarks

    CPU 16 bits

    GPM745B0 Mechanical Features

    Dot Resolution

    240(RGB)×320 (QVGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    125 PPI

    Aspect Ratio

    3:4 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.0675×0.2025 mm (H×V)

    Pixel Pitch

    0.2025×0.2025 mm (H×V)

    Active Area

    48.6×64.8 mm (H×V)

    Outline Dimension

    57.54×79.2 mm (H×V)

    Outline Depth

    4.6 (Typ.) mm

    Landscape or Portrait

    Portrait type

    Touch Panel

    Embeded (4-wire Resistive)

    GPM745B0 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    250 cd/m² (Typ.)

    Contrast Ratio

    200 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Response Time

    10/20 (Typ.)(Tr/Td)

    White color Chromaticity

    Wx:0.312; Wy:0.341

    Transmissivity

    4.7% (Typ.)(with Polarizer)

    Sunlight Readable

    N

    GPM745B0 Electronics Feature

    Driver IC

    Built-in SPFD5408A-C1

    GPM745B0 Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    Lamp Amount

    1S5P

    Lamp Shape

    5 strings

    Lamp Voltage

    3.1/3.6V (Min./Max.)

    Lamp Current

    15mA (Typ.)

    Lamps Power Consumption

    270mW (Typ.)

    Interface Type

    Included in panel signal interface

    Lamp Driver Board

    No

    GPM745B0 Signal Interface

    Signal Category

    CPU

    Signal Class

    CPU

    Input Voltage for Panel

    2.8V (Typ.)

    Input Current for Panel

    8.25/16.5mA (Typ./Max.)

    Interface Type

    FPC
