CMO 14.1inch N141C3-L08 LCD Panel

    Buy cheap CMO 14.1inch N141C3-L08 LCD Panel from wholesalers

    Buy cheap CMO 14.1inch N141C3-L08 LCD Panel from wholesalers
    • Buy cheap CMO 14.1inch N141C3-L08 LCD Panel from wholesalers

    CMO 14.1inch N141C3-L08 LCD Panel

    Ask Lasest Price
    Brand Name : CMO
    Certification : RoHS Compliant
    Model Number : N141C3-L08
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    CMO 14.1inch N141C3-L08 LCD Panel

    CMO 14.1inch N141C3-L08 LCD Panel

    Specification for N141C3-L08:

    N141C3-L08 Basic Information

    Panel Model

    N141C3-L08

    Panel Brand

    CMO

    Descrition

    a-Si TFT-LCD ,14.1 inch, 1440×900

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    N141C3-L08 Mechanical Features

    Dot Resolution

    1440(RGB)×900 (WXGA+)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    120 PPI

    Aspect Ratio

    16:10 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.07025×0.21075 mm (H×V)

    Pixel Pitch

    0.21075×0.21075 mm (H×V)

    Weight

    400/415g (Typ.Max.)

    Surface

    Antiglare, Hard coating (3H)

    Active Area

    303.48×189.675 mm (H×V)

    Bezel Area

    306.76×193.0 mm (H×V)

    Outline Dimension

    319.5×205.5 mm (H×V)

    Outline Depth

    5.2/5.5 (Typ./Max.) mm

    Shape Style

    Wedge (PCBA Bent, Depth ≥5.2mm)

    Holes & Brackets

    Side mounting holes (8-M2) on left, right bezel

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    N141C3-L08 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    200 cd/m² (Typ.)

    Contrast Ratio

    600 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Response Time

    3/7 (Typ.)(Tr/Td)

    Viewing Angle

    45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    6 o'clock

    White color Chromaticity

    Wx:0.313; Wy:0.329

    White Variation

    1.40 (Max.)(5 points)

    Sunlight Readable

    N

    N141C3-L08 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    N141C3-L08 Backlight System

    Lamp Position

    Edge light type (Bottom side)

    Lamp Type

    CCFL

    Lamp Amount

    1 pcs

    Lamp Shape

    Straight

    Lamp Life Time

    15K(Min.) (Hours)

    Lamp Voltage

    680±68V

    Lamp Current

    2.0/6.0/6.5mA (Min./Typ./Max.)

    Lamp Operating Frequency

    45/80KHz (Min./Max.)

    Lamp Startup Voltage

    1370/1520V (Max.)(Ta=+25/0℃)

    Lamps Power Consumption

    4.08W (Typ.)

    Interface Type

    Connector

    Lamp Driver Board

    No

    N141C3-L08 Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (2 ch, 6-bit)

    Input Voltage for Panel

    3.3V (Typ.)

    Input Current for Panel

    360/450mA (Typ./Max.)

    Interface Type

    Connector

    Signal Interface

    JAE - FI-XB30SRL-HF11, Pitch:1.0 mm, Pin:30 pins
