HITACHI 5inch TX13D200VM0BAA LCD Panel

    Buy cheap HITACHI 5inch TX13D200VM0BAA LCD Panel from wholesalers

    Buy cheap HITACHI 5inch TX13D200VM0BAA LCD Panel from wholesalers
    • Buy cheap HITACHI 5inch TX13D200VM0BAA LCD Panel from wholesalers

    HITACHI 5inch TX13D200VM0BAA LCD Panel

    Ask Lasest Price
    Brand Name : HITACHI
    Certification : RoHS Compliant
    Model Number : TX13D200VM0BAA
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    HITACHI 5inch TX13D200VM0BAA LCD Panel

    HITACHI 5inch TX13D200VM0BAA LCD Panel

    Specification for TX13D200VM0BAA:

    TX13D200VM0BAA Basic Information

    Panel Model

    TX13D200VM0BAA

    Panel Brand

    HITACHI

    Descrition

    a-Si TFT-LCD ,5.0 inch, 640×480

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -30 ~ 80 °C

    Storage Temperature

    -40 ~ 90 °C

    Remarks

    Rugged+

    TX13D200VM0BAA Mechanical Features

    Dot Resolution

    640(RGB)×480 (VGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    159 PPI

    Aspect Ratio

    4:3 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.053×0.159 mm (H×V)

    Pixel Pitch

    0.159×0.159 mm (H×V)

    Surface

    Antiglare

    Active Area

    101.76×76.32 mm (H×V)

    Bezel Area

    104.8×79.36 mm (H×V)

    Outline Dimension

    119.4×89.1 mm (H×V)

    Outline Depth

    9.3±0.5 mm

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    TX13D200VM0BAA Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    600 cd/m² (Typ.)

    Contrast Ratio

    500 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Color Gamut

    60% NTSC (CIE1931)

    Response Time

    45 (Max.)(Tr+Td)

    Viewing Angle

    80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)

    White color Chromaticity

    Wx:0.310; Wy:0.340

    White Variation

    1.43 (Max.)(9 points)

    Sunlight Readable

    N

    TX13D200VM0BAA Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    Yes (U/D, L/R)

    TX13D200VM0BAA Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    Lamp Life Time

    70K(Typ.) (Hours)

    Interface Type

    Included in panel signal interface

    Lamp Driver Board

    12.0V (Typ.)

    TX13D200VM0BAA Signal Interface

    Signal Category

    TTL

    Signal Class

    CMOS (1 ch, 6-bit)

    Input Voltage for Panel

    3.3V (Typ.)

    Input Current for Panel

    360/410mA (Typ./Max.)

    Panel Power Consumption

    1.2W (Typ.)

    Interface Type

    Connector

    Signal Interface

    JAE - FA5S040HP1, Pitch:0.5 mm, Pin:40 pins
