AUO 17inch B170WP04 V0 LCD Panel

    Buy cheap AUO 17inch B170WP04 V0 LCD Panel from wholesalers

    Buy cheap AUO 17inch B170WP04 V0 LCD Panel from wholesalers
    • Buy cheap AUO 17inch B170WP04 V0 LCD Panel from wholesalers

    AUO 17inch B170WP04 V0 LCD Panel

    Ask Lasest Price
    Brand Name : AUO
    Certification : RoHS Compliant
    Model Number : B170WP04 V0
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    AUO 17inch B170WP04 V0 LCD Panel

    AUO 17inch B170WP04 V0 LCD Panel

    Specification for B170WP04 V0:

    B170WP04 V0 Basic Information

    Panel Model

    B170WP04 V0

    Panel Brand

    AUO

    Descrition

    a-Si TFT-LCD ,17.0 inch, 1440×900

    Panel Type

    a-Si TFT-LCD

    Model Alias

    B170WP04 V.0

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    B170WP04 V0 Mechanical Features

    Dot Resolution

    1440(RGB)×900 (WXGA+)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    99 PPI

    Aspect Ratio

    16:10 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.085×0.255 mm (H×V)

    Pixel Pitch

    0.255×0.255 mm (H×V)

    Weight

    0.96/1.1Kgs (Typ./Max.)

    Surface

    Glare (Haze 0%)

    Active Area

    367.2×229.5 mm (H×V)

    Bezel Area

    370.9×233.2 mm (H×V)

    Outline Dimension

    382.2×246.8 mm (H×V)

    Outline Depth

    10.0 (Max.) mm

    Shape Style

    Wedge (PCBA Bent, Depth ≥5.2mm)

    Holes & Brackets

    Side mounting holes (8-M2) on left, right bezel

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    B170WP04 V0 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    500 cd/m² (Typ.)

    Contrast Ratio

    700 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Color Gamut

    72% NTSC (CIE1931)

    Response Time

    6/2 (Typ.)(Tr/Td)

    Viewing Angle

    70/70/60/60 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    6 o'clock

    White color Chromaticity

    Wx:0.338; Wy:0.346

    White Variation

    1.25/2.0 (Max.)(5/13 points)

    Sunlight Readable

    N

    B170WP04 V0 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    Total Power Consumption

    12.5W (Typ.)

    B170WP04 V0 Backlight System

    Lamp Position

    Edge light type (Bottom side)

    Lamp Type

    CCFL

    Lamp Amount

    2 pcs

    Lamp Shape

    Straight

    Lamp Voltage

    745/785/905V (Min./Typ./Max.)

    Lamp Current

    3.0/6.5/7.0mA (Min./Typ./Max.)

    Lamp Operating Frequency

    45/60/80KHz (Min./Typ./Max.)

    Lamp Startup Voltage

    1250/1500V (Max.)(Ta=+25/0℃)

    Lamps Power Consumption

    5.4/9.6/10.4W (Min./Typ./Max.)

    Interface Type

    Connector

    Lamp Driver Board

    No

    B170WP04 V0 Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (2 ch, 6-bit)

    Input Voltage for Panel

    3.3V (Typ.)

    Input Current for Panel

    600/700mA (Typ./Max.)

    Panel Power Consumption

    3.0W (Max.)

    Interface Type

    Connector

    Signal Interface

    JAE - FI-XB30SL-HF10, Pitch:1.0 mm, Pin:30 pins
