SAMSUNG 23inch LTA230AN03-W LCD Panel

    Buy cheap SAMSUNG 23inch LTA230AN03-W LCD Panel from wholesalers

    Buy cheap SAMSUNG 23inch LTA230AN03-W LCD Panel from wholesalers
    • Buy cheap SAMSUNG 23inch LTA230AN03-W LCD Panel from wholesalers

    SAMSUNG 23inch LTA230AN03-W LCD Panel

    Ask Lasest Price
    Brand Name : SAMSUNG
    Certification : RoHS Compliant
    Model Number : LTA230AN03-W
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    SAMSUNG 23inch LTA230AN03-W LCD Panel

    SAMSUNG 23inch LTA230AN03-W LCD Panel

    Specification for LTA230AN03-W:

    LTA230AN03-W Basic Information

    Panel Model

    LTA230AN03-W

    Panel Brand

    SAMSUNG

    Descrition

    a-Si TFT-LCD ,23.0 inch, 1366×768

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    LTA230AN03-W Mechanical Features

    Dot Resolution

    1366×768(RGB) (WXGA)

    Pixel Configuration

    RGB Horizontal Stripe

    Pixel Density

    68 PPI

    Aspect Ratio

    16:9 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.372×0.124 mm (H×V)

    Pixel Pitch

    0.372×0.372 mm (H×V)

    Weight

    1.70Kgs (Max.)

    Surface

    Antiglare (Haze 2.3%), Hard coating (2H)

    Active Area

    508.152×285.696 mm (H×V)

    Bezel Area

    513.8×290.8 mm (H×V)

    Outline Dimension

    534×311.8 mm (H×V)

    Outline Depth

    11±0.5 mm

    Holes & Brackets

    Side mounting holes (4-M3) on left, right bezel

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    LTA230AN03-W Optical Features

    Display Mode

    PVA, Normally Black, Transmissive

    Brightness

    250 cd/m² (Typ.)

    Contrast Ratio

    4000 : 1 (Typ.) (Transmissive)

    Display Color

    16.7M (8-bit)

    Color Gamut

    68% NTSC (CIE1931)

    Response Time

    8 (Typ.)(G to G)

    Viewing Angle

    89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    Symmetry

    White color Chromaticity

    Wx:0.285; Wy:0.311

    White Variation

    1.43 (Max.)(9 points)

    Sunlight Readable

    N

    LTA230AN03-W Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    LTA230AN03-W Backlight System

    Lamp Position

    Edge light type (Right side)

    Lamp Type

    WLED

    Lamp Shape

    1 string

    Lamp Life Time

    30K(Min.) (Hours)

    Lamp Voltage

    96.4/103.6/110.9V (Min./Typ./Max.)

    Lamp Current

    120/125mA (Typ./Max.)

    Lamps Power Consumption

    11.6/12.1/13.6W (Typ./Max.)

    Interface Type

    Connector

    Interface Position

    Lamp Driver Board

    No

    LTA230AN03-W Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (1 ch, 8-bit)

    Input Voltage for Panel

    12.0V (Typ.)

    Input Current for Panel

    216/316mA (Typ./Max.)

    Interface Type

    Connector

    Interface Position
