Description: FTTH Flat indoor drop optical fiber Cable LSZH sheath
![1276828325708_hz-myalibaba-temp11_380[1].jpg](https://img.burrillandco.com/nimg/49/c4/a85e8c8ce1917c6be95df2167de4.jpg)
Description
The optical fiber unit is positioned in the center. Two parallel
Fiber Reinforced Plastic (FRP) are placed at two sides. Then the
cable is completed with a black or colour LSZH sheath.
1.2 core FTTH Flat indoor drop optical fiber Cable LSZH sheath
2.two number strength members
3.indoor optical fiber cable
Features
--Special low-bend-sensitivity fiber provides high bandwidth and
excellent communication property.
--Two parallel FRP strength members ensure good performance of
crush resistance to protect the fiber.
--Simple structure, light weight and high practicability.
--Novel flute design, easily strip and splice, simplify the
installation and maintance.
--Low smoke, zero halogen and flame retardant sheath.
Dimensional Characterstics
| Part Number | Fiber Count | Nominal Cable Diameter
(mm) | Nominal cable weight
(kg/km) |
| KTFTTH-IQ-WH-0209 | 2 | (2.0±0.2) x (3.0±0.2) | 8.0 |
| KTFTTH denotes Kontoon FTTH cable; IQ denotes colored fiber; WH
denotes white sheath; |
| 02 denotes 2 coloured fibers, 09 denotes singlemode G652 fibers |
FTTH indoor cable spec.:
Fiber count | Cable Diameter (mm) | Cable Weight (kg/km) | Tensile (N) Long/ Short term | Crush (N/100mm) Long/ Short term | Min. Bend Radius (mm) Dynamic/ Static |
1 | (2.0±0.2)×(3.0±0.2) | 8 | 30/60 | 300/1000 | 15/30 |
2 | (2.0±0.2)×(3.0±0.2) | 8.5 | 30/60 | 300/1000 | 15/30 |
4 | (2.0±0.2)×(3.8±0.2) | 9 | 30/60 | 300/1000 | 15/30 |
6 | (2.0±0.2)×(3.8±0.2) | 9.5 | 30/60 | 300/1000 | 15/30 |
8 | (2.0±0.2)×(4.8±0.2) | 13 | 30/60 | 300/1000 | 15/30 |
12 | (2.0±0.2)×(5.8±0.2) | 16 | 40/80 | 400/1200 | 15/30 |
Note: Range of temperature: -30~+70°C |
Application:
1. Directly installed into houses
2. Access network, fiber to the home
3. End users use directly indoor cabling, indoor pipe cabling
4. Support the internet, CATV and telephone, Support more network increase service in future
Order Optional Information:
l Jacket material: PVC (Environmental lame-retardant
polyvinylchloride), LSZH (Environmental low smoke zero halogen
flame retardant polyolefin), or other customerized material.
l Jacket color: blue, orange, green, brown, gray, red, black,
yellow, and violet, pink, aqua.
l Fiber type: B1-G.652, B1.3-G.652.D, B4-G655, A1-50/125μm,
A1b-62.5/125μm, M1-Maxband 150, M3-Maxband 300, M5-Maxband 550, E1-
EasyBad G.657, E1.1- EasyBad Plus G.657, etc.
l Cable Dimension: the nominal cable dimension, or other
constomerized dimension;
l Fiber Count: total number of fibers in the cable
l MOQ: 1km~2km, or other customerized
