    ASTM D6055 Packaging Test Equipment With PLC Control , HD-A535

    Ask Lasest Price
    Brand Name : HAIDA
    Certification : ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
    Model Number : HD-A535
    Price : Negotiable
    Delivery Time : 20 days after order confirmed
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
    Supply Ability : 300 Sets per Month Haida
    • Product Details
    • Company Profile

    ASTM D6055 Packaging Test Equipment With PLC Control , HD-A535

    ASTM D6055 Packaging Test Equipment With PLC Control , HD-A535


    Introduction


    The ISTA Package Clamping Force Testing Machine is simulated the impact strength of packaging in the real circumstance of transportation, for example, the transportation of goods. This product is applied to the scientific research institutions, colleges, packaging technique test centers, packaging material manufacturers and foreign trade or transportation departments.

    Design Standard


    ASTM D642, ASTM D6055, American SEARS enterprise standard.

    Technical Parameters of ISTA Package Clamping Force Testing Machine:

    ItemsSpecification
    Sample shapeparallelepiped transport package;
    Maximum test weight500KG
    Clamping pressure400-3000Lb (adjustable) pressure can be applied on the corresponding surface according to the transportation diagram on the test sample;
    Plywood sizeH48in * D48in
    Clamping plate height adjustment0-1000mm
    Lifting speed50-300mm / min, set fixed speed
    Spreading plate width200-2000mm
    Dimensions2000 * 2800 * 2350mm
    Sensor accuracy1/100000
    Measurement accuracy1%
    Clamping displacement accuracy± 0.5MM
    Power controllerThe computer displays the maximum power value in Chinese and English
    Splint requirementsTwo gripping plates are 2000lb parallel and flat without deformation under working conditions, the vertical state between the splint and the floor, the thickness of the splint is ≥15mm, the splint can realize the action and cycle of clamping, opening, rising, and lowering cycle
    Automatic stop modeset the upper and lower limits to stop
    Transmission modeservo motor controls clamping force, and AC motor controls rise and fall
    Protection deviceleakage protection, travel limit device
    Can be connected to a computer
    Working voltageAC 220V / 50HZ

    More Related Product Welcome to click here
    Haida ISTA Series Testing Machine.pdf
