    SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules

    Ask Lasest Price
    Brand Name : LINK-PP
    Certification : UL,RoHS,Reach,ISO
    Model Number : SM51589L
    Price : $0.06-$3.2
    Delivery Time : Stock
    Payment Terms : TT,NET30/60/90 Days
    Supply Ability : 3KK/Month
    • Product Details
    • Company Profile

    SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules

    SM51589L , SM51589PEL LAN 10/100/1000 Base-T Transformer (PoE) Modules

    Features
    ■ Compliant with IEEE802.3 standards
    ■ Designed for 10/100/1000 Base-T and PoE
    ■ 1500 VDC dielectric withstanding voltage
    ■ RoHS compliant*

    Turns Ratio TX/RX....................1CT:1CT
    Cross Talk
    30 MHz ...............................45 dB min.
    60 MHz ...............................40 dB min.
    80 MHz ...............................35 dB min.
    Insertion Loss
    1-100 MHz .......................-1.0 dB max.
    Return Loss (@ 100 Ohms)
    1-30 MHz ............................18 dB min.
    40 MHz ............................14.4 dB min.
    50 MHz ............................13.1 dB min.
    60-80 MHz ..........................12 dB min.
    100 MHz .............................10 dB min.
    PRI OCL (@100 KHz,
    0.1 V, 8 mA, DC Bias) ..... 350 μH min.
    DCMR
    30 MHz ...............................43 dB min.
    60 MHz ...............................37 dB min.
    80 MHz ...............................33 dB min.
    PoE Current .................Up to 600 mADC
    for 1000 Base-T
    Isolation Hi-Pot ...........1500V, 1 mA,
    2 seconds
    Operating Temperature
    ..................................-40 °C to +85 °C

    Quality SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules for sale
