Black / Blue 14 Way Male Champ Centronic Connector For PCB Board with board lock

    Buy cheap Black / Blue 14 Way Male Champ Centronic Connector For PCB Board with board lock from wholesalers

    Buy cheap Black / Blue 14 Way Male Champ Centronic Connector For PCB Board with board lock from wholesalers
    • Buy cheap Black / Blue 14 Way Male Champ Centronic Connector For PCB Board with board lock from wholesalers
    • Buy cheap Black / Blue 14 Way Male Champ Centronic Connector For PCB Board with board lock from wholesalers

    Black / Blue 14 Way Male Champ Centronic Connector For PCB Board with board lock

    Ask Lasest Price
    Brand Name : FUYCONN
    Certification : UL 94-V0, ROHS-certified, ISO 9001:2008, ISO 14001:2004
    Model Number : FUY57022
    Price : Negotiable
    Delivery Time : 7-10 days
    Payment Terms : T/T or Paypal
    Supply Ability : 1 million/ month
    • Product Details
    • Company Profile

    Black / Blue 14 Way Male Champ Centronic Connector For PCB Board with board lock


    Black / Blue 14 Way Male Champ Centronic Connector For PCB Board



    Detail Description:
    Type: Straight Angle PCB Connector
    Product Category: Centronic connector
    PCB Mount Style:Vertical
    Product Line: Champ Connector
    Number of Terminal: 14 pin
    Gender: Male
    Connector Style:Plug
    Insulator Color: Black or Blue
    Insulator Material: PBT
    Contact pin Material: Phosphor Bronze
    Shield Plating: Nickel
    Centerline = 2.16mm [0.085in]
    Mating Lock: Back Rivet Boardlocks
    Application: PCB Board


    Advantage:
    1,ROHS compliant, UL-approved
    2,High quality, Competitive price
    3,Quick delivery time
    4,Free sample available in 2 days



    Common Features

    Designed for Cable-to-cable and cable-to-PC Board applications
    Board Application
    Available in Plug & Socket styles
    Terminal Option with various types
    Connector and hood sold as complete assembly
    Available in low profile hood style
    Metal shell provides grounding and shielding capability
    Mates with industry compatible connector


    Product Features

    Product Type:Centronics PCB Mounting Connector
    Product Line:Champ Connector
    Gender:Male
    Connector Style:Plug
    Certerline :2.16mm(0.85in)
    Number of Position:14 pin
    Contact Plating:Gold Plating (1U", 3U", 5U" ,10U", 15U", 30U")
    Terminals TypeStraight Terminals
    Insulator Color:Black or Blue
    Shielded:Yes
    Orientation:Parllel Lines
    Mating connector lock:Screws Lock


    Materials

    Contact Material:Phosphor Bronze
    Insulator:PBT (UL 94-V0)
    ShellNickel Plated Steel


    Electrical Character

    Current Rating:5Amp
    Withstanding Voltage:AC 1000v r.m.s
    Insulation Resistance:1000 Megohms Minimum at DC 500V
    Contact Resistance:25M∩ Max Mated
    Operation Temperature:-55°C to +105°C
