| Brand Name : | DGKYD |
| Certification : | RoHS/CE/UL/FCC/CE/ISO9001/ISO14001 |
| Model Number : | KRJ-109YGZDEYNL |
| Price : | Please contact us to get the latest price. |
| Delivery Time : | 10 days |
| Payment Terms : | T/T, D/P, D/A, L/C, Western Union, MoneyGram |
| Supply Ability : | 100K pcs/day |
| ATTRIBUTE | ATTRIBUTE VALUE |
|---|---|
| TEMPERATURE | -40 to +85℃ |
| SPEED | 100BASE-TX |
| SHIELD PLATING MATERIAL | NICKEL |
| SHIELD EMI TABS | YES |
| SHIELD | METAL SHIELD |
| ROHS COMPLIANT | YES |
| PANEL STOP | YES |
| PCB MOUNT ANGLE | RIGHT ANGLE |
| PACKAGE | THT |
| NUMBER OF POSITIONS | 8 |
| NUMBER OF PORTS | RJ45 |
| NUMBER OF CONTACTS | 8 |
| LED OPTION | Y/G |
| LATCH | DOWN |
| NUMBER OF PORTS | 1X1 |
| HOUSING MATERIAL | PBT UL94V-0 |
| CONTACT MATING AREA PLATING | GOLD 6U |
| CONNECTOR TYPE | RJ45 |
| CONNECTOR MATERIAL COLOR | YELLOW |



RJ45 ,in order to keep good touch between gold finger and crystal head,should paint the gold on the surface,there is 6u,15u,30,50u,usually use 6u,according to customer’s request and cost to proceed, gold finger insert and pull life should be 750 times above.
LED Specifications:
Emitting | Dominant wavelength(nm) | Forward voltage | Forward current | Type |
Green | 570-575 | 1.8-2.4 | 20mA | Squareness |
Yellow | 585-590 | 1.8-2.4 | 20mA | Squareness |
|
