    HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers

    Ask Lasest Price
    Brand Name : ZGMC
    Model Number : Wear Resistant Plate
    Certification : ISO TUV SGS BIS CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,OA
    Supply Ability : 5000Tons Per Months
    Delivery Time : 5-15days depend on the quantity
    • Product Details
    • Company Profile

    HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers

    NM400 is a high-strength wear-resistant steel plate known for its excellent wear resistance and toughness. Here are some key features, applications, and common information about NM400:
    Features:
    Wear Resistance: NM400 exhibits exceptional resistance to abrasion, erosion, and impact, making it suitable for harsh working environments with high wear and tear.
    High Strength: It possesses high strength and hardness, allowing it to withstand heavy loads and impact forces.
    Weldability: NM400 offers good weldability, allowing for ease of fabrication and assembly.
    Machinability: It can be machined using conventional methods, enabling the production of complex parts and components.
    Applications:
    Mining and Construction Machinery: NM400 is extensively used in mining equipment, earth-moving machinery, dump truck bodies, excavator buckets, and wear liners for crushers and chutes.
    Material Handling: It finds applications in industries involving bulk material handling, such as conveyor systems, hoppers, and wear-resistant liners.
    Cement and Steel Production: NM400 is utilized in cement plants, steel mills, and foundries for equipment subjected to abrasion and impact, including crushers, hoppers, and cyclones.
    Recycling and Waste Management: It is applied in waste sorting and recycling equipment, shredders, and wear plates for waste containers and compactors.
    Common Information:
    Standard: NM400 complies with the Chinese standard GB/T 24186-2009 for wear-resistant steel plates.
    Hardness: NM400 typically exhibits a hardness range of 360 to 440 HBW (Brinell hardness).
    Thickness and Size: NM400 is available in thicknesses ranging from 3mm to 100mm, with common widths of approximately 1500mm to 3000mm and lengths of 3000mm to 12000mm.
    International Equivalents: NM400 is comparable to internationally recognized wear-resistant steel grades such as Hardox 400 (Sweden) and AR400 (USA).
    NM400's exceptional wear resistance, high strength, and versatility make it a preferred choice for various industries requiring durable and abrasion-resistant materials.
    Chemical Composition Of NM 400 Plates
    NM 400 Chemical Compositiom
    PlateCSiMnPSCrNiMoB
    thickness mmmax %max %max %max %max %max %max %max %max %
    3-(8)0.150.71.60.0250.010.30.250.250.004
    8-200.150.71.60.0250.010.50.250.250.004
    (20)-320.180.71.60.0250.0110.250.250.004
    (32)-450.220.71.60.0250.011.40.50.60.004
    (45)-510.220.71.60.0250.011.40.50.60.004
    (51)-800.270.71.60.0250.011.410.60.004
    (80)-1300.320.71.60.0250.011.41.50.60.004
    Mechanical Properties for NM 400 High Tensile Plate
    Mechanical properties of NM 400
    GradeMechanical PropertyCharpy V Impact Test
    NM 400YieldTensileElongationDegreelongitudinal
    Min MpaMpaMin %-40J
    100012501045
