PVC Coated 50X200mm High Quality 3D Bending Curved Welded Wire Mesh
Farm Garden Fence Panel
Product Description:
3D Panel Fence is also known as curvy welded fencing, triangle mesh
fence, welded wire fence, etc.
3D Panel Fence is one of the most important ways to keep your home
safe and secured from all forms of attacks by armed robbers and so
on.
Welded Wire Mesh Fencing is very affordable and inexpensive that is
why we see most homes using wire fencing for their walls and also
very durable and easy to make and fix on fences.
The surface treatment of 3D Panel Fence includes: hot-dipped
galvanized, PVC coated, powder coated
| Height | 630mm,830mm,1030mm,1230mm,1530mm,1630mm,1730mm,1830,,.1930mm,2030mm,2230mm,2430mm |
| Width | 2000mm,2500mm,2900mm |
| Wire diameter | 3.0mm, 3.5mm, 4.0mm, 4.5mm, 5.0mm |
| Mesh opening | 50*100mm, 50*150mm, 50*200mm, 75*100mm, etc |
| Clamp | Metal clamp/Anti-UV plastic clamp/no clamp(for peach post) |
| Post | Round post(48OD*1.5/2.0mm, 60OD*1.5/2.0mm)
Square post(50*50*1.5/2.0mm, 60*60*1.5/2.0mm, 80*80*1.5/2.0mm)
Rectangular post(40*60*1.5/2.0mm, 40*80*1.5/2.0mm, 60*80*1.5/2.0mm,
80*100*1.5/2.0mm) |
| Post cap | Metal cap/Anti-UV plastic cap |
Generally, the number of V-shaped curves varies as the height of
welded wire mesh varies.
If the fence height falls between 630 mm and 1430 mm, it will have
2 folds; if the fence height falls between 1530 mm and 1930 mm, it
will have 3 folds; if the fence height falls between 2030 and 2430,
it will have 4 folds as shown below.
Fence posts
- Material: high grade steel for maximum strength and rigidity.
- Post section: 60 × 60 mm, 80 × 80 mm, 100 × 100 mm or 120 × 120 mm.
- Post Plate thickness: 2.5/3.0/4.0/5.0 mm.
- Finish: inside and outside galvanized (Min. 275 g/m2), subsequently
covered with a polymer powder (Min. 60 micron ).
- Colors: Green RAL 6005, or Black RAL 9005.
- Post cap: metal caps or plastic cap.
- Metal clips and clamps are hot dip galvanised then powder coating
in green or black color.
Advantages of Galvanized 3D Welded Wire Mesh Panel:
1. Aesthetics beauty looking.
2. Wild scope of using.
3. Thick coated with rust resistance.
4. Economic and long service life.
Post and all kits:
We provide posts and its all kits for the galvanized 3D welded wire
mesh fence, and the size can be customized as well.
metal clamps
metal clamps-02
Workshop&Packing:
Qijie Wire Mesh MFG Co.,ltd is a professional manufacturer of
fences, wire mesh products with more than 20 years experience.
Welcome to visit our factory located in Anping city at any time!
