    High Temperture Rubber Heat Aging Test Chamber, RT+10°C ~500°C

    Ask Lasest Price
    Brand Name : BOTO
    Model Number : BT-0-150L
    Certification : CE ISO
    Price : Negotiated
    Payment Terms : T/T
    Supply Ability : 200 Set/Sets per Month High Temperture Rubber Heat Aging Test Chamber have stock
    Delivery Time : 1-15 days,to be negotiated
    • Product Details
    • Company Profile

    High Temperture Rubber Heat Aging Test Chamber, RT+10°C ~500°C

    High Temperture Rubber Heat Aging Test Chamber, RT+10°C ~500°C

    Products Description

    Introduction:

    High Temperature Oven can provide a stable test space for preheating, drying, changes about physics and chemistry testing . It supplies precision temperature controller with high stability of platinum resistance to temperature that makes temperature well-distribution.Applications:Plastic Rubber Materials,Adhesive Tape,Food,Pharm,Daily-used chemical,etc.
    Product Paramenters
    Product Name
    High Temperature Oven
    Model Number
    BT-O-150L
    Power
    1 phase 220V 50Hz
    Cable Port
    External Power
    Interior Size
    (W*H*D)
    50*60*50cm(W*H*D)
    Exterior Size
    (W*H*D)
    69*110*64cm(W*H*D)
    Customized Size
    Acceptable
    Control Method
    PID ,PID automatically adjust the output


    Advantages
    1.Precision temperature controller provides accurate, stable conditions of constant temperature, in order to facilitate the test
    or dry conducted.

    2.The liquid expansion over-temperature power protection devices, to ensure the safety of the test article.

    3.With adjustable air intake and exhaust ports, according to the test conditions of different options ,Choose to resize or switch.

    4.Timing device for LED Digital constant timing, providing complete use Conditional design.

    5.Machine can be designed rely on customers requirements,such as the test cable hole,casters,controller’s position ect.

    6.Machine continuous running time is above three month

    7.Alarm device ,when over-temperature protection action and timing is complete ,that alarm will inform and automatic shut down.
    Temp Control Fluctuation
    ± 1.5℃
    Temperature Range
    RT+10℃~300℃
    Accuracy
    ±0.5℃
    Temperature Resolution
    0.1
    Temperature Uniformity
    ±2℃
    Power
    4.8KW
    Key Set of
    Data Input
    Resolution 0.1 ℃
    ntegration time(IT):
    0~3600s
    Derivative time(DT):
    0~900s
    Built-in timer function
    Protection Device
    Motor overload protection
    Buzzer
    Fault indicator
    No fuse protection switch
    Heating Up Time
    (NO-load)
    RT~160℃ about 28min
    Temp Controller
    The microcomputer automatically calculus controller


    Chamber Materials
    1.Inner chamber materials:SUS stainless steel plate
    2.External chamber materials:Special steel, galvanized anti-rust treatment, outside with Advanced wear-resistant resin paint
    coating.
    3.Insulation material: aluminum silicate glass wool
    4.The clapboard Material: Stainless Steel
    5.Stainless steel electric heater Material: fin heat pipe type
    6.Time control: 0 ~ 999H/M/S adjustable.
    7.The rmometry body: T thermocouple
    Air Supply Method
    Galvanized wind wheel forced air circulation, the left and right into the return air to ensure uniformity of temperature, not
    cause direct damage of high temperature ,when open the door.
    Use of The Environment
    Allowable temperature range of 0 ~ 35 ℃
    Details Images
    Company introduction

    BOTO GROUP Ltd. is a private enterprise integrating r&d, production, OEM and sales of scientific and technological equipment manufacturing. Proficient in the production, development and upgrading of various non-standard instruments and automatic instruments. The factory covers an area of 26,666 square meters, headquartered in Shanghai, has several offices in China, the factory annual output of about 2000 sets of equipment. Since the establishment of the company, the company is committed to providing customers with quality products and services, and has been praised by customers.



    In the domestic market, we have many end customers, third-party testing institutions, research institutes, leading enterprises in different industries, and some agents. For the overseas market, we hope to find more general agents, distributors and importers to cooperate together.



    The factory has the ability to calibrate, and the customer can also designate a third party organization to calibrate and issue a calibration report.
