Product Description:
Single-Conductor Wire is a single-wire cable designed for a wide
range of electrical applications. This cable is made with a PVC
insulation material and is rated to 90°C. The conductor size of
this cable is 18 AWG and is composed of copper material. This cable
is UL Style 1015-certified for quality assurance.
Single-Conductor Wire is ideal for use in a variety of
applications, including residential, commercial, and industrial
settings. It is durable, reliable, and offers superior electrical
performance. This cable is easy to install and has a long service
life. It is a great choice for projects requiring single-conductor
wire.
Features:
- Product Name: Hookup Wire
- Single-Conductor Wire
- Single-Wire Cable
- Conductor Size: 18 AWG
- Insulation Material: PVC
- Conductor Material: Copper
- Temperature Rating: 90°C
Technical Parameters:
| Parameter | Value |
|---|
| Application | Equipment |
| Temperature Rating | 90°C |
| UL Style | 1015 |
| Conductor Stranding | 7x26 |
| Shield Type | Unshielded |
| Voltage Rating | 600V |
| Reference Standard | UL758,UL1581 |
| NEC Type | THHN |
| Jacket Material | PVC |
| Insulation Material | PVC |
FAQ:
Q&A
- Q1: What's the Brand Name of Single Conductor Wire?
- A1: The Brand Name of Single Conductor Wire is XSD Cable.
- Q2: What is the Model Number of Single Conductor Wire?
- A2: The Model Number of Single Conductor Wire is Single Conductor
Wire.
- Q3: Where is the Place of Origin of Single Conductor Wire?
- A3: The Place of Origin of Single Conductor Wire is
Guangdong,China.
- Q4: What Certifications does Single Conductor Wire have?
- A4: Single Conductor Wire has UL,CE,ISO:9001 Certifications.
- Q5: What is the Minimum Order Quantity of Single Conductor Wire?
- A5: The Minimum Order Quantity of Single Conductor Wire is
3050Meters.
