01. Adopt epson I3200-A1 heads. max speed up to 120Sq/H
A.Printing width of I3200-A1 is 1.3 inch,about 30% wider than DX5,printing speed can reach
120sqm/h with 3heads,also with 3200 nozzles(400*8lines),it has much
higher speed and resolution than Dx5.
B.EPS3200 printhead adopts TFP technology,with the smallest droplet
2.5PL,variable dots technology,can ensure perfect and high
resolution printing performance.
C.EPS3200 printhead has very cheap price,only about 300-350USD/pc
now,which helps client reduce cost to get more benefit!
D.Compared with Epson 5113 heads,the ink column makes hoses
connection much easier and more simple,very convenient maintenance.
2. Anti-collision Car ,the distance between printhead and printing platform can be adjusted
freely according to different printing consumables. Anti-collision
devices are added at both ends to provide more comprehensive safety
protection for printheads.
4. Advanced Capping Station
Equipped with advanced intelligent printhead cleaning and
moisturizing device, it provides safe and convenient printhead
cleaning and maintenance functions,which can also pump ink well and
keep the ink flow fluently. Operation and maintenance is more
convenient.
4. High Quality THK mute guide rail and slider .More stable
running,longer working life,lower noise.higher resolution,and fewer
errors in length.
5. Leadshine Motor Both the servo and stepping systems are driven
by high-quality brushless integrated Leadshine motor with
high-precision linear decoding, smaller error,higher precision and
more stable operation.
6. Large Capacity & Two Stage Ink Reservoirs .Four units of 3L
super large capacity ink reservoirs provide ink independently and
continuously, which guarantees the long-term continuity of ink
output,and keep wide format high-speed printing wonderfully.Two
stage ink supply system provides more guarantee for non-stop ink
output.
8. Intelligent Ink Starving Alarm . Intelligent ink deficiency
alert reduces the tediousness of frequently checking ink margin,
and promptly reminds to add ink to ensure the continuity of
printing work.
9. Intelligent Air-heat Dryer , two-stage heating, middle warm air and smart start-stop technology,
ensure the drying performance and more energy-saving at the same
time.
10. Air Shaft Media Feeding and Take-up System. When working it's
not necessary to fix the printing media with other accessories,
just use the pressure of air to adjust automatically,which can
offer uniform force to make the paper movement smoother. This
system has the characteristics of
1. large load bearing capacity.
2. long service life.
3. Uniform force on media feeding and collecting.
4. Short aeration and deflation operation time, etc.
11. Intelligent Foggy Printing & VSDT Printing. Unique
two-dimension intelligent foggy and wave-foggy function, and
effective banding elimination in printing,improve printing quality
obviously.VSDT variable droplet techonology can offer the smallest
droplet as 3.5PL to the largest droplet as 27PL, then achieve the
prefect printing quality.
