Ilfield Sucker Rod Pump/Tubing Pump Api 11ax Oil Well Down Hole Sucker Rod Pump

    Buy cheap Ilfield Sucker Rod Pump/Tubing Pump Api 11ax Oil Well Down Hole Sucker Rod Pump from wholesalers

    Buy cheap Ilfield Sucker Rod Pump/Tubing Pump Api 11ax Oil Well Down Hole Sucker Rod Pump from wholesalers
    • Buy cheap Ilfield Sucker Rod Pump/Tubing Pump Api 11ax Oil Well Down Hole Sucker Rod Pump from wholesalers

    Ilfield Sucker Rod Pump/Tubing Pump Api 11ax Oil Well Down Hole Sucker Rod Pump

    Ask Lasest Price
    Brand Name : ZS
    Model Number : 20-125 To 30-250
    Certification : API 11AX
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 1000sets/month
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    Ilfield Sucker Rod Pump/Tubing Pump Api 11ax Oil Well Down Hole Sucker Rod Pump

    API 11AX DOWNHOLE SUCKER ROD PUMP

    Product Description

    Various pumps and spare parts conform to API SPEC 11AX, and special pumps can be
    designed and manufactured such as heavy crude oil pumps, sand-proof pumps and Gas-proof pumps

    according to the requirements of users. Key parts of the pumps can be made of materials with

    strong corrosion-resistance and excellent mechanical properties conform to NACE stdMR-01-76

    according to various well conditions.


    Barrel Type:


    1. Plating barrel, 67HRC-71HRC

    2. Chemical material plating barrel, corrosive medium is difficult to invade, it's suitable for oilwells which have more corrosive medium.


    Spray plunger:


    1. HRC is greater than 53.

    2. The spray surface is solidly combined with pump bodies.


    Valve Type:


    1.Stainless steel valve seat and ball, with competitive price.

    2.Stellite valve seat and ball, high hardness, corrosion-resisting.


    The barrel assembly and the standing valve assembly of the pump can be mounted and connected to the tubing on the ground, which are run into the well first, then connect the plunger assembly with the lower end of the sucker-rod and run them into the pump.


    Tubing pump has the characteristics as large flow rate, tight and sound structure.


    Standing valve has two types: non-pullable and pullable. The pullable standing valve tubing pump has cup type and mechanical type.


    Specification table:

    12345

    Type of Pump


    Letter Designation
    Metal Plunger PumpsSoft-Packed Plunger Pumps

    Heavy-Wall Barrel


    Thin-Wall Barrel


    Heavy-Wall Barrel


    Thin-Wall Barrel

    Rod Pumps
    Stationary Barrel, Top AnchorRHARWARSA
    Stationary Barrel, Bottom AnchorRHBRWBRSB
    Stationary Barrel, Bottom AnchorRHTRWTRST
    Tubing PumpsTH--TP--

    Main parts process and material:
    Pump barrel: plain carbon steel plating (A1), ordinary carbon steel carbonitriding (B1), ordinary carbon steel carburizing (B2), low alloy steel nitride (B5).
    Plunger: 1045 steel spraying (B1), 1045 steel spraying (B2), 1045 steel chrome plating (A1), 1045 steel double chrome plating (A2).
    Valve ball and seat: stainless steel (A1), cobalt chromium (B2), tungsten carbide (C1), nickel and carbon compounds (C2), titanium carbide (C3).
    Other accessories: plain carbon steel, low alloy steel, stainless steel, brass and other materials.


    Company Information

    Puyang Zhongshi Group Co., Ltd is a professional manufacturer of various oilfield equipments and cementing accessories since 1997, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.

    We have the certificates of API 5CT, API 10D, API 11E, API 6A, API 11AX, ISO 9001 and ISO 14001. Our foreign customers are mainly from America, Central Asia, Russia, Southeast Asia, Middle East, etc.
