    25T Axle Load Railway Train Axle Gauge 1435mm Reliable AAR / GOST / TSI Standard

    Ask Lasest Price
    Brand Name : Railteco
    Model Number : Class E
    Certification : AAR/GOST/TSI/IRIS/ISO
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : Annual capacity of 40000 pcs
    Delivery Time : 45 to 60 days after advance payment
    • Product Details
    • Company Profile

    25T Axle Load Railway Train Axle Gauge 1435mm Reliable AAR / GOST / TSI Standard

    Railway Axle Class E Axle For Freight Wagon Standard Gauge Railroad Wagon Axles Train Axle Wagon Axle Bogie Axle AAR / GOST / TSI Axle


    Description of Railway Axle:


    An axle is the component of a wheelset, a wheelset is the wheel–axle assembly of a railroad car. Axles are an integral component of most practical wheeled vehicles. In a live-axle suspension system, the axles serve to transmit driving torque to the wheel, as well as to maintain the position of the wheels relative to each other and to the vehicle body. The axles in this system must also bear the weight of the vehicle plus any cargo. A non-driving axle, such as the front beam axle in heavy duty trucks and some two-wheel drive light trucks and vans, will have no shaft, and serves only as a suspension and steering component. Conversely, many front-wheel drive cars have a solid rear beam axle.


    Freight Wagon Axle of Type E Standard Gauge


    Parameter
    Axle load25t
    Rail Gauge1435mm
    Axle length2235.2mm
    Journal Diameter144.539mm
    Wheel seat Diameter209.55mm
    Bearing center distance1981.2mm
    MaterialLZ50, JZ45, AAT Grade F, EA1N, EA1T, EA4T, IRS 16/95, SFA60A, and et.
    StandardsTB/T 2945, AAR M-101, UIC 811-1, EN 13261, BS 5892 PART 1, IRS 16/95, JIS E 4502, KSR 9220, GOST 31334, AS 7515 and other customer's requirement.
    TestsChemical analysis, Metallographic, Mechanical analysis, Ultrasonic testing, Magnetic testing, Impact testing, Hardness testing, Surface quality and dimension report.
    CertificationsISO9001, ISO14001, OHSAS18001, AAR, IRIS, TSI.


    Quality 25T Axle Load Railway Train Axle Gauge 1435mm Reliable AAR / GOST / TSI Standard for sale
