High mast lights 1000w outdoor led high mast light led light for
basketball court
With a variety of items to choose from, you’re guaranteed to find a
flood light that fits your needs and looks how you want. All of our
LED flood and area lights also have a lifespan of 50,000 hours and
come in a variety of wattages and color temperatures
Product Features
Instantaneous start, easy installation and complete with an
efficient optical design
Four kinds of beam angle to meet different lighitng requirement
By using waterproof connector and silicon rubber sealing, up to
IP66, meeting the requirements for harsh, tough environment
1, High Luminous Efficiency: up to 120lm/w
2, Multiple options of beam angle to meet different application
requirement: 10°, 25°,45°,60°
3, Quick And Easy Installation
4, Dual protection, Intelligent Working Mode
5, To be compatible with Light control system.
6, Low weight for easy mounting and maintenance.
7, Simple design and practical
8, Intelligent Working Mode. Support Longer working time as Well as
Energy saving
9, High Transparency and High Efficiency
Advantages:
Better Light Maintenance
More modules are available for higher power to 1200Watt
Aluminum housing, Anti-corrosion, can be adjusted to any
circumstances
There are four lamp beads in one lens, which has better lighting
effect
Die-cast aluminum alloy housing
Modular design, free combination of full power, more convenient
maintenance and management
Brackets and a single module can be adjustable.
High light transmittance, small light attenuation, prolong life,
more than ten years life
Rugged die-cast aluminum adjustable bracket that can be horizontal
or vertical mounted
Technical Parameter
Product Technical Parameter |
Model. | GY620TG | GY462TG |
Power(W) | 800/1000/1200 | 400/500/600 |
Input Voltage(V) | AC100~300 |
PF | ≥0.95 |
CRI | Ra70/80 |
CCT(K) | 3000/4000/5000/5700K |
IP Rating | IP66 |
Beam Angle | 10° | 25° | 45° | 60° |
Lighting Efficiency(lm/W) | 100 | 100~150 |
Working Temperature(℃) | - 40 ～40 ℃ |
Working Relative Humidity(RH) | 0 ～90% |
Net Weight(KG) | 25kg | 14kg |
Material | Die- casting aluminum + PC lens |
Note:
For 10° the led chips are 3535 chip(100-110lm/w); other beam angles
are 5050(130-150lm/w).
Scope of application:
LED flood lights provide general area lighting for various
commercial and residential applications
Main indoor and outdoor stadiums, squares, factories, airports, docks, highway intersections, billboards, buildings, and other
flood-lighting places.
