Product Description:
The Soil Cement Mixing Plant is widely used to produce high-quality
stabilized soil cement mixtures. It is an ideal choice for
construction projects such as road, railway, bridge, and airport
construction.
The Soil Cement Mixing Plant features a modular design, which
allows for the addition of multiple components, such as stone
powder silos, dust collectors, and cement silos, to create a
complete production line. The twin-shaft forced concrete mixer is
equipped with a unique mixing blade, which ensures high-efficiency
mixing and a uniform mixture. The PLC system allows for easy
operation and monitoring of the production process. The Soil Cement
Mixing Plant is reliable, durable, and easy to maintain, making it
an ideal choice for any construction project.
Product configuration:
1, Batching supply system: dividing hopper, speed-controlled
frequency-controlled metering belt machine, belt conveyor.
2, Cement material supply system: cement silo (cement hopper),
speed-controlled variable frequency metering impeller feeder,
spiral electronic weighing conveyor.
3, Automatic water supply system: pressure tank, submersible pump,
pipeline, pressure reducing valve, water flow meter, water
sprinkler.
4, Mixing system: motor reducer, double horizontal shaft continuous
mixer.
5, Storage bin device system: double discharge storage bin,
inclined belt machine, air compressor.
6, Electrical system: operation control cabinet, operation room.
7, Measuring control system: Adopt domestic famous manufacturer
electronic parts, frequency conversion speed control, microcomputer
control manual and automatic two forms. This machine is equipped
with bulk cement silo, (including screw conveyor). For bagged
cement hopper, it can be equipped with another device according to
the user's needs.
Technical Parameters:
WDJ300.400.500.600.700.800 type stabilized soil mixing plant main
performance parameters:
| Parameter Model | WDJ300 | WDJ400 | WDJ500 | WDJ600 | WDJ700 | WDJ800 |
| Productivity | 300t/h | 400t/h | 500t/h | 600t/h | 700t/h | 800t/h |
| Measuring method | Computerized | Computerized | Computerized | Computerized | Computerized | Computerized |
| Adjustment method | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control |
| Control mode | automatic | automatic | automatic | automatic | automatic | automatic |
| Weighing accuracy (aggregate) | ±2% | ±2% | ±2% | ±2% | ±2% | ±2% |
| Weighing accuracy (powder) | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Main motor power | 37KW | 45KW | 60KW | 75KW | 90KW | 110KW |
| Total Weight | 24t | 24t | 27t | 27t | 30t | 30t |
| Total power | 115KW | 125KW | 140KW | 155KW | 180KW | 200KW
|
Soil Cement Mixing Plant Technical Support and Services include:
- Installation, commissioning, and maintenance support
- Customized engineering solutions
- Troubleshooting and technical advice
- On-site training and operator support
- Long-term spare parts supply and service
- Online and telephone support
FAQ:
Soil Cement Mixing Plant FAQs
Q1: What is the Soil Cement Mixing Plant?
A1: The Soil Cement Mixing Plant is a machine that is designed to
produce a consistent mix of soil and cement in a short period of
time.
Q2: What is the capacity of the Soil Cement Mixing Plant?
A2: The Soil Cement Mixing Plant can produce up to 60 tons of soil
and cement mix per hour.
Q3: What fuels does the Soil Cement Mixing Plant use?
A3: The Soil Cement Mixing Plant is powered by diesel, natural gas,
or electric.
Q4: How should the Soil Cement Mixing Plant be operated?
A4: The Soil Cement Mixing Plant should be operated in accordance
with the manufacturer's instructions.
Q5: What is the average life expectancy of the Soil Cement Mixing
Plant?
A5: The average life expectancy of the Soil Cement Mixing Plant is
approximately 10 years with proper maintenance.
