Features:
1.Perforated wooden acoustic panel is manufactured from 100%
polyester fibers and does not contain chemical binders including
formaldehyde.
2.Perforated wooden acoustic panel products contains a minimum of
75% previously recycled polyester fiber (from PET bottle
flake)ensuring comparatively low embodied energy.
3.Its polyester non-woven surface is easy to be bonded and fit for
most kinds of surface sheet.
4.Absorb reverberated sound, providing acoustic control to lessen
the amount of noise in a room
5.Protect and adorn your walls, providing high-impact wall
protection while serving as a viscous surface, giving the same
functionality as a bulletin board without sacrificing aesthetics
6.Easy-to-install, cuts, fastens, and paints easily, less
maintenance, more life;
7.It is widely used for acoustic walls, acoustic ceilings, computer
rooms, TV station, gymnasium, theater,office, cinema, church,
hospital etc.
| Acoustic panel type | Polyester Acoustic Panels |
| General use | Interior decoration, sound abosorbing |
| NRC | 0.7~0.95,SGS Test for polyester fiber acoustic panel |
| Environmental | SGS E0,Non- toxic, non -allergenic |
| Color | Can be customiced |
| Material | 100% recyled polyester fiber |
| Size | 1220*2420mm |
| Thickness |
12 / 15 / 18 mm |
| Weight Range | 1600gsm and 2000gsm in stock for polyester fiber acoustic panel |
| Composition | 100% Polyester Fiber (PET) |
| Position | Interior or exterior |
Product Specifications
Product Name:Polyester fiber acoustic panel
Composition:100% Polyester Fiber (PET)
Panel Dimensions :2420*1220mm or other Custom size
Thickness :(+/– 10%) 9mm and 12mm color in stock or
3mm.6mm.15mm,24mm.48mm
Weight: (+/– 5%)
1400g/sqm(155kg/m3).1650g/sqm(183kg/m3).2000g/sqm(222kg/m3) for 9mm
in stock.
2400g/sqm(200kg/m3) for 12mm in stock.
2800g/sqm(117kg/m3) for 24mm
Density:1lb/cubic foot=16kg/m3.
Installation-procedures
1.Messuring the size of the wall.Marking sure the installation
position,horizontal line and vertical line.Setting aside enough
space for eelectric wire socket,tubs and so on.
2According-to-the-actual-size-of-the-place,-caculate-and-cut-some-panels-and-keels.Thenleave-aside-space-for-socket,-tube-and-other-thing.
3The-installation-order-must-obey-the-principle-from-left-to-right,-from-below-to-above-when-installed-horizontally-the-panel-leaves-its-female-side-above.-When-installed-vertically,-its-female-side-is-on-the-right.
4Fix-the-panel-on-the-keel.
5.Use-the-screw-to-fix-on-the-side.-When-installing-the-right-o
upper-keel,-leave-1.5mm-horizontally-for-expansion-and-then-use-the-silica-to-seal-it-up
Applications:
It is suitable for office, meeting room, auditorium, KTV,
exhibition room, stadium, hotel ect.
Polyester acoustic panel is an ideal decorative and acoustic
material, made of
100% polyester fiber with density of 229kg/M3. It's has good performance: eco-friendly, fire-
resistance, heat insulation, moisture-proof and mildew. Many patterns and colours are available to meet different levels of acoustic styles and decorative
requirements.
