Sliding Aluminium Partition Roller Hotel Soundproof Partition Wall
Operable Walls
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather,
Insulation board, Fireproof board, Wall paper, Vinyl, Painting,
etc. (Customized) |
Specification:
The soundproof wall partition is a kind of operable wall that can
divide a large space into a small space or a small space into a
large space at any time according to needs and has a general wall
function. It can serve as a multi-purpose room with multiple
functions.
The soundproof partition has the characteristics of easy
installation, reliability, industrial production, fire prevention,
and environmental protection.
Soundproof partition wall feature:
Hinged pair panels for quick and easy operation.
Robust aluminum frame construction for demanding environments.
Room divider wide range of surface finishes.
Partial and fully operating panels available.
Partition divider just only top hung supported without floor track.
Introduction:
The soundproof partition wall is our individual panel partition
system offering an acoustic insulation rating of up to 53 dB.
Ideally suited for high specification applications due to the sheer
flexibility, numerous stacking arrangements available and the
impressive acoustic qualities this system offers.
The panels are operated by means of an internal scissor-jack
mechanism and move effortlessly along an aluminium head track, when
closed they form a secure fixed wall.
Movable wall system is a high quality bespoke movable wall system
to suit timber panels up to 150 kilograms in weight, there are
multiple options for Door types, parking areas and track layouts.
Each door is a top hung straight sliding panel which sits inline
with the other doors these panels can be moved into a parking area
when the wall needs to be opened, pivot panels can be fixed or
converted into sliding doors. Timber movable walls can be created
to suit any space within reason.
Main material:
Soundproof partition paint-free decorative material has a natural
texture, clear wood grain, and can be compared with logs. There are
all kinds of wood species popular in the world, and there is no
color difference on the surface of the product.
The product design is elaborate, the color matching is reasonable,
the construction is convenient, and the saw is good.
Cut, never rupture, repair and trim, use paint-free line matching,
glue with glue, no need to worry about ash after nailing, and no
need to paint, can save labor and paint fee after construction,
avoid paint on the human body Unhealthy odor and carcinogens not
only save a long-term maintenance and care costs, but also shorten
the construction time, the effect is elegant, the cost is reduced,
so it is green, non-toxic, tasteless, pollution-free cross-century
new generation of paint-free decoration Materials, products lead
the new trend of decorative materials with their benefits.
The movable partition paint-free plate is one of the decorative
plates. It has the characteristics of washing, abrasion resistance,
moisture resistance, etc. and is economical. It is a good helper
for modern decoration partitions.
Our service:
We design and manufacture value for money products with a one year
warranty on all the outstanding ranges illustrated in this
brochure.
We offer a complete service package covering site surveys, CAD
technical drawings, and quotation presentation. Emphasis is placed
on quality assurance backed by a comprehensive after sales service.
