    In 2021 XCMG SCHWING Used HB30K-4X Concrete Pump Truck 30 Meter

    Ask Lasest Price
    Brand Name : XCMG SCHWING
    Model Number : HB30K-4X
    Price : Negotiable
    Payment Terms : T/T、L/C、D/A、D/P
    Supply Ability : 1pcs/month
    Delivery Time : 18days
    • Product Details
    • Company Profile

    In 2021 XCMG SCHWING Used HB30K-4X Concrete Pump Truck 30 Meter

    In 2021 XCMG SCHWING 30 meter Used HB30K-4X Concrete Pump Truck

    Product features and advantages:

    1: Manufacture date: 2021

    2: Pump working time: 1200 hours

    3: conveying square quantity of concrete:30000 cubic meters

    4: Very favorable prices for sale


    XCMG Schwing technical parameters of HB 30 K-4X 30 m concrete pump truck:

    Here are the technical specifications of the XCMG HB30K-4X 30m concrete pump truck:
    1: Model: HB30K-4X
    2:Maximum theoretical conveying distance: 30m
    3:Maximum theoretical conveying height: 29.7m
    4:Maximum theoretical conveying depth: 17.5m
    5:Pumping pressure: 8MPa
    6:Pumping frequency: 18 times/min
    7:Chassis configuration: XCMG self-produced chassis
    8:Engine power: 132kW
    9:Engine emission standard: China National V
    10:Hydraulic system pressure: 32MPa
    11:Hydraulic oil tank capacity: 300L
    12:Total weight: 11800kg
    13:Overall dimensions: 7750mm×2250mm×2960mm


    Technical parameters of XCMG HB 30 K-4X 30 m concrete pump truck pumping system:

    Here are the technical specifications of the pumping system for the XCMG HB30K-4X 30m concrete pump truck:
    1:Main pump model: K3V112D
    2:Main pump displacement: 112ml/r
    3:Main oil cylinder diameter x stroke: ø100×1400mm
    4:S-tube valve type for distribution valve
    5:Supporting pump model: 50DWBX
    6:Supporting pump displacement: 50ml/r
    7:Oil tank capacity: 600L
    8:Hydraulic system pressure: 32MPa
    9:Pumping pressure: 8MPa
    10:Pumping frequency: 18 times/min


    XCMG Schwing HB 30 K-4X 30 m concrete pump truck uses HOWO chassis technical parameters:

    Here are the technical specifications of the SINOTRUK HOWO chassis used for the XCMG HB30K-4X 30m concrete pump truck:
    1:Chassis model: ZZ5307N4647E1
    2:Engine model: WD615.95E, compliant with China National V emission standard
    3:Engine power: 247kW
    4:Maximum torque: 1350N.m
    5:Displacement: 9.726L
    6:Cab type: HW76 long cab, single berth, with air conditioning
    7:Transmission model: HW19710, 10 forwards and 2 reverse gears manual transmission
    8:Drive type: 6×4, rear-wheel drive
    9:Wheelbase: 4025+1350mm
    10:Tire specifications: 12.00R20 steel wire tire
    11:Fuel tank capacity: 300L
