Product Description:
Tricone Rock Bit is a rotary rock bit with three blades and
tungsten carbide teeth. It has a hex shank and weighs 2.5kg. Each
blade is 2.5mm thick. This bit is designed for drilling through
hard rocks and minerals such as granite, quartz, sandstone, basalt,
and shale. It offers maximum strength and resistance to wear, as
well as maximum penetration rates and drilling efficiency. It is
also capable of drilling horizontally, vertically, and in any other
direction with equal efficiency. The tungsten carbide teeth provide
superior performance in drilling through difficult rocks. The
tricone rock bit is the perfect tool for mining and drilling
operations in various industries.
Features:
- Product Name: Tricone Drilling Bit
- Cutting Edge: Cone
- Shape: Tricone
- Material: Tungsten Carbide
- Weight: 2.5kg
- Connection: Pin
- Type: Roller Cone Bit, Rotary Rock Bit
Technical Parameters:
| Attribute | Value |
|---|
| Product Name | Tricone Drilling Bit |
| Cutting Structure | Milled Tooth |
| Connection | Pin |
| Weight | 2.5kg |
| Teeth | 3 |
| Cutting Edge | Cone |
| Shank Type | Hex |
| Blade Thickness | 2.5mm |
| Blade Angle | 90° |
| Blade Width | 6mm |
| Blade Height | 8mm |
| Roller Cone Bit | Yes |
| Tungsten Carbide Bit | Yes |
| Rotary Rock Bit | Yes |
Applications:
Tricone Drilling Bit is made of tungsten carbide, which is
certified by ISO 9001. Its size is 3 7/8, thread type is API Reg,
and the shank type is Hex. The price is negotiable, and the weight
is only 2.5kg. The packaging could be customized according to the
customer needs, and the delivery time is 15-30 work days. Besides,
TT payment terms are acceptable. The Tricone Drilling Bit is widely
used in rotary rock drilling fields.
Tricone Drilling Bit is a kind of tungsten carbide bit, which is
made of selected high-grade tungsten carbide. It has excellent wear
resistance and impact strength, and its shank type is Hex. It is
certified by ISO 9001 and made in Hebei, China. The size of the bit
is 3 7/8, and the thread type is API Reg. The weight is only 2.5kg,
and the price is negotiable. The packaging could be customized
according to the customer needs, and the delivery time is 15-30
work days. Payment terms are TT.
Tricone Drilling Bit is a reliable and cost-effective solution for
rotary rock drilling operations. It is made of tungsten carbide,
which provides excellent wear resistance and impact strength. The
size is 3 7/8, and the thread type is API Reg. It is certified by
ISO 9001 and made in Hebei, China. The weight is only 2.5kg, and
the price is negotiable. The packaging could be customized
according to the customer needs, and the delivery time is 15-30
work days. Payment terms are TT.
| Bit Size | Connection | Making Up Torque | Weight | Bit Size | Connection | Making Up Torque | Weight |
| Inch | mm | Inch | KN.m | Kg | Inch | mm | Inch | KN.m | Kg |
| 3 1/2 | 95.3 | 2 3/8 | 4.1~4.7 | 5 | 11 | 279.4 | 6 5/8 | 38~43.4 | 85 |
| 4 5/8 | 117.5 | 2 7/8 | 6.1~7.5 | 6.5 | 11 5/8 | 295.3 | | | 89 |
| 4 3/4 | 120.7 | | | 7 | 12 1/8 | 304.8 | | | 94 |
| 5 1/2 | 139 2/3 | 3 1/2 | 9.5~12.2 | 17 | 12 1/4 | 311.2 | | | 95 |
| 5 7/8 | 142.9 | | | 18 | 12 15/32 | 315.9 | | | 97 |
| 6 | 152.4 | | | 19.5 | 13 1/8 | 333.4 | | | 120 |
| 6 1/4 | 158.8 | | | 19.5 | 13 5/8 | 346.1 | | | 120 |
| 6 1/2 | 165.1 | | | 19.5 | 13 3/4 | 349.3 | | | 120 |
| 6 3/4 | 171.5 | | | 21 | 14 5/8 | 368.3 | 7 5/8 | 46.1~54.2 | 160 |
| 7 1/2 | 190.5 | 4 1/2 | 16.3~21.7 | 28 | 14 3/4 | 374.7 | | | 160 |
| 7 7/8 | 200 | | | 29.5 | 15 | 381 | | | 185 |
| 8 1/4 | 209.6 | | | 38 | 15 1/2 | 393.7 | | | 189 |
| 8 3/8 | 212.7 | | | 38 | 16 | 406.4 | | | 205 |
| 8 1/2 | 215.9 | | | 38 | 17 1/2 | 444.5 | | | 255 |
| 8 3/4 | 222.3 | | | 40 | 20 | 508.0 | | | 443 |
| 9 1/2 | 241.3 | 6 5/8 | 38~43.4 | 57.5 | 22 | 558.8 | | | 580 |
| 9 7/8 | 250.8 | | | 60 | 24 | 609.6 | | | 650 |
| 10 5/8 | 269.9 | | | 74 | 26 | 660.4 | | | 810 |
Customization:
We provide custom services for Tricone Drilling Bit. Our Tricone
Drilling Bit is made of high-quality Tungsten Carbide and has a
Thread Type of API Reg, Connection of Pin and Size of 3 7/8. It
also has a Blade Width of 6mm and Number of Blades of 3. Our
Tricone Rock Bit is of ISO9001 certification and has a reasonable
Price. The packaging and Delivery Time can be customized according
to customer needs and the Payment Terms is TT. Place of Origin is
Hebei, China.
FAQ:
- Q: What is the place of origin of Tricone Drilling Bit?
- A: The place of origin of Tricone Drilling Bit is Hebei, China.
- Q: Does Tricone Drilling Bit have any certification?
- A: Yes. Tricone Drilling Bit has ISO9001 certification.
- Q: What is the price of Tricone Drilling Bit?
- A: The price of Tricone Drilling Bit is negotiable.
- Q: What is the packaging details of Tricone Drilling Bit?
- A: The packaging details of Tricone Drilling Bit is according to
customer needs.
- Q: How long is the delivery time of Tricone Drilling Bit?
- A: The delivery time of Tricone Drilling Bit is 15-30 work days.
- Q: What are the payment terms of Tricone Drilling Bit?
- A: The payment terms of Tricone Drilling Bit is TT.
