    Corrugated Paper UV Spot Laminator Coating Machine 1050mm 9000Sheets Per Hour

    Ask Lasest Price
    Brand Name : ECOOGRAPHIX
    Model Number : ECOO 1050SD
    Certification : CE
    Price : 10000-100000USD
    Payment Terms : L/C, T/T
    Supply Ability : 500SETS
    Delivery Time : 30DAYS
    • Product Details
    • Company Profile

    Corrugated Paper UV Spot Laminator Coating Machine 1050mm 9000Sheets Per Hour

    Corrugated Paper UV Spot Laminator Coating Machine 1050mm 9000Sheets Per Hour


    High Speed UV Spot and Overall Coating machine adopts upper-swaygripper- pass -sheet method to enable max speed up 9000 sheets/hour. UV curing system with Teflon conveying belt has characteristic of higher speed, precise orientation and UV curing higher efficiency and lower power consumption. After sheet travelling through UV coater and being transferred directly by teflon belt, grippers cannot be heated by high temperature from UV light, which prevent them from being damaged or deformed to ensure easy maintenance.


    PRODUCT DESCRIPTION
    * The machine is suitable for using water-based glue, solvent-based glue, and thermal film.
    * Cold-water non-curling system: The paper will be non-curling after separated.
    * Low cost: Ceramic anilox roller coating, minimize gluing amount to 5g/sqm.
    * The heating energy cycle drying system makes the whole machine power consumption about 30kw/h.
    * High efficiency:The machine working speed reaches to 70m/min, 10000sheets/h.


    Remarks:
    Laminating speed depend on paper weight, film thickness and gule material quality.
    Subject to change without notice.
    Standard Configuration: Selectable Configuration:

    Auto Feeder

    Multifunctional Coating Unit

    UV Curing System

    Auto Delivery Unit

    Auto Control

    ModelEcoo SD-1050
    Max.sheet size730x1050mm
    MIN.sheet size310X406mm
    Max.coating size720x1040mm
    Sheet thickness80-500gsm
    Coating registration accuracy±0.2mm
    Production speed9000sheets/hour
    Weight8T
    Dimension10460x2725x1930mm
    Power44KW
    Remark: Production speed depending on sheet weight, size and quality
