Automatic Optical Cable Stripper
I. Summary
1. This model is mainly for the strippling of 1.8mm to 3.0mm indoor
optical cables in the current optical communication industry
(peeling and shearing openings 3 in 1).
2. This machine adopts PLC control system, which is accurate and
fast.
3. Touch screen is easy to operate, learn and understand.
4. Peeling, shearing, cutting speed, stable performance, high
accuracy, easy to adjust the length (25mm-38mm).
5. The number of stripping, shearing and cutting optical cables per
hour is 1500-1800pcs.
6. Improve the traditional peeling method with pedal press, and
evolve into direct insertion, which not only saves physical
strength, but also improves the efficiency .
7. Moving the cabling front and rear the operation, the ordinary
indoor simplex cable with the outer diameter of 1.8 mm to 3.0 mm
can be used on this machine, without changing the cutter, and
without the worry of pinching fingers.
II. Specifications
| 1 | Use atmospheric pressure: | 0.6-0.8 MPa |
| 2 | Power supply: | 220V 50Hz |
| 3 | Weight: | 25kgs |
| 4 | Volume: | 405 x 415 x 445 mm |
