SPCC Cold Rolled Steel Sheet Thickness 0.3 - 2.5mm CR Sheets ASTM
JIS GB Standard
| Material: | A516, A537, Q345R, Q235, Q255, Q275, SS400, A36, SM400A, St37-2,
SA283Gr, S235JR, S235J0, S235J2 DC01 ST12 ST37 |
| Thickness: | 0.2-500mm, etc |
| Width : | 1000-4000mm, etc |
| Length: | 2000mm, 2438mm, 3000mm, 3500, 6000mm, 12000mm, or rolled, etc |
| Standard: | ASTM, AISI, JIS, GB, DIN, EN |
| Technique: | Cold Rolled, Hot Rolled |
| Certification: | ISO, SGS, BV |
| price terms: | FOB, CRF, CIF, EXW all acceptable |
| Delivery Detail: | inventory About 5-7, custom-made 25-30 |
| Packing: | standard export packing (inside: water proof paper, outside: steel
covered with strips and pallets) |
| Payment Terms: | T/T, L/C at sight, West Union, D/P, D/A, Paypal |
SPCC cold-rolled steel sheet is general and steel, its chemical
composition and mechanical properties equivalent to China Q195
grade and Q215A. Wherein the third letter C is Cold Cold
abbreviations. When the need to ensure the tensile test, the grades
at the end plus T SPCCT.
SPCC Definition
In the Japanese JIS standard, cold-rolled carbon sheet has several
grades such as SPCC, SPCD, SPCE, among which the latter two
represent cold-rolled carbon sheets for stamping and deep drawing,
which are equivalent to the 08AL high-quality carbon in China’s
13237 standards. Plain structural steel and 08AL deep drawing steel
in the 5213 standards.
SPCC indicates that a cold-rolled carbon sheet is generally used,
which is equivalent to China’s Q195-Q215A. No stamping test is
required. The tensile test must be ensured. Add T after the grade
to indicate SPCC-T or SPCCT.
PCC cold-rolled sheet steel is representative of stamping steel in
cold-rolled sheets. Because of its excellent stamping performance
and beautiful appearance, it is widely used in household
appliances, automobiles, and chemical industries. It has gradually
become high demand, excellent quality, and economical Steel
products with considerable benefits.
SPCC steel chemical composition :
| Grade | C | Mn | P | S |
| SPCC | ≤0.15 | ≤0.60 | ≤0.100 | ≤0.05 |
SPCC steel Mechanical Properties
| Grade | Yield Strength | tensile strength | Elongation |
| SPCC | ≤240 | ≥270 | ≥28 |
JIS G3141 SPCC steel sheet application:
JIS G3141 SPCC steel sheet, steel strip, under JIS G3141 standard,
JIS G3141 SPCC steel sheet, steel strip is a kind of cold rolled
carton steel sheet and steel strip, the main characteristics of
this steel are low or very low carton, it contain fine grain and
Ti, Nb alloy elements. it has a wide application in auto body,
gear, transmission shaft, pinion steel, crankshaft, cold forging
steel for standardized parts and components, and so on.
