3 Axle U - Shape Van Type Heavy Duty Dump Truck / Hydraulic Rear
Dump Truck
Description:
Chassis:Heavy duty and extra durability designed I beam;opting for high
tensile steel Q345,
Top plate 18mm .bottom plate 20mm .middle plate 10mm .height:500mm
Landing gear:Fuwa two-speed,manual operating ,heavy duty landing gear 28
Vehicular applications:Sand and pebble and mineral transport
Braking system:WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
Paiting:Complete chassis sand blasting to clean rust ,1coat of
anticorrosive prime,2coats of final paint
Specifications:
| Types of | Dumper Truck |
| Rated quality | 12740 |
| total mass | 25000 |
| curb weight | 12130 |
| Fuel type | diesel fuel |
| number of axes | 3 |
| wheelbase | 3625+1350 |
| Axle load | 7000/18000 (two-axis group) |
| Number of tires | 10 |
| approaching the departure angle | 14/26 |
| front suspension rear suspension | 1500/1670,1500/1739 |
| Front track | 20,222,041 |
| rear track | 1830/1830 |
| vehicle length | 8145, |
| vehicle width | 2496, |
| vehicle height | 3450 |
| Cargo length | 5400, |
| Cargo width | 2300, |
| Cargo height | 950, |
| top speed | 82 |
| The number of occupants in the cab | 2 |
| Carrier Mass Utilization Coefficient | 1.06 |
MORE DETAILED PICTURES:
Advantage:
- 1. Diverse function to load different constuction materias
- 2. Diverse load capacity from 20ton -55tons
- 3. Diverse design for tipper box as request
- 4. Diverse design curb weight for road regulations
Related Production:
Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( 55470323, 54640582, 54640443, 54622108, 54621778,
54621524, water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump
truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted
crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer,
tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting
crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
