    IGBT Inverter High Frequency Induction Gold Melting Furnace 1KG-5KG Capacity

    Ask Lasest Price
    Brand Name : OURUIDA
    Model Number : HF-15KW
    Certification : CE ,ISO, ROHS,GSG
    Price : Negotiation
    Payment Terms : L/C, D/P, T/T, D/A, Western Union
    Supply Ability : 10000SETS /Month
    Delivery Time : 1-5days
    • Product Details
    • Company Profile

    IGBT Inverter High Frequency Induction Gold Melting Furnace 1KG-5KG Capacity

    Hot sales High Frequency Induction melting Gold furnace machine for1KG -5KG(HF-15KW)

    Product Description:


    Induction melting is a process where metal is melted into liquid form in the crucible of an induction furnace. The molten metal is then poured from the crucible, usually into a mould. Evolgy has developed solutions within a variety of areas such as precious metals, tilting furnace melting, investment casting and lab applications.

    • Induction melting is clean, so it is possible to skip the purification stage
    • Uniform heat induced in the metal contributes to a high-quality end result
    • Advanced ergonomic features make workplaces safer and increase productivity.

    Medium and high frequency gold melting furnaces can be customised at any time for special melting furnaces for the jewellery industry, melting (gold, silver, copper, platinum, palladium, etc.) 1-50 kg at a time, up to 2 minutes/furnace, stability tank level 24 hours a day.

    Induction melting furnace Features:

    1. All solid IGBT frequency power adjustment, a unique cooling circulation system, ensure that the equipment 24hours of continuous work.

    2. Automatically adjust the heating power and heating time, manual adjustment is available.

    3. With constant current/ constant power control ability.

    4. Small and light body (floor space less than 1 square meter), easy to move to another place.

    5. No danger working, safe operation, available for many situations like factory, school, home, and research institution, etc.

    6. High security, with various protection as over voltage protection, over and current protection, insufficient water protection over heating protection and other self-protection. safe and reliable.

    7. 100% continuous duty cycle - 24hours working ability under full loading.

    8. Environment friendly, low pollution and noise.

    9. Digital automatic control, easily understand the work condition from the indicator lights and figures.

    10. Cost-effective high frequency induction heating machine, one set can be used for many application, though changing the induction heating coils.

    Technical specifications

    Type HF-15AB/15A
    Work Power 220V,230V,240V 50-60hz
    380V*3Phase
    The range of operating voltage 200-260VAC 340-430V
    Output power 15KW
    Input current 36A
    Fluctuating frequency 30-100khz
    Timing (Heat time,Retain time,Cool time) 1-99S
    The flow rate of cooling water 0.15 Mpa 7.6L/Min
    Water temperature protection point 40centidegree
    Duty cycle 100% (40degree room temperature)
    Weight 36Kg
    Size Main Parts:640*280*550mm

    Induction Heating machines are application in area:

    PACKAGE:

    Quality IGBT Inverter High Frequency Induction Gold Melting Furnace 1KG-5KG Capacity for sale
