RBSC silicon carbide tube ceramic burner nozzle used in industrial
furnance.
silicon carbide products
• Simple installation, even in existing radiant tube systems
• Flame tubes can be made to any length by combining individual
flame tube segments
• Patented flame tube segment design allows flame tube to be bent
• Reduced strain on radiant tubes due to light-weight design
• Long service life due to ceramic material SiSiC which is
resistant to high temperatures
Specifications according to user requirements can be produced.
Major Feature:
1.corrosion resistance,high precision surface
2. wear resistance, high strength
3.oxidation resistance,long application life
4. light weight. easy to be made into kinds of forms
5. high temperature tolerance.
SISIC products are widely used in industrial production
a)Automobile Industry
b)Boiler Industry
c)Chemical Industry
d)Crystallite Glass Industry
e)Magnetic Materials Industry
f)Metallurgy
g)Metallurgy Industry
h)Paper Industry
i)Petroleum Industry
The SISIC Burner Nozzles are used for tunnel kiln,shuttle kiln,
roller hearth kiln as the flame tubes.The burner nozzles are also
used for heating on either direct or indirect furnace systems.
The SISIC Burner Nozzles has excellent heat and wear resistance,
oxidation resistance, shock resistance, high strength, no residue,
no crack, long service life, convenient replacement.
| Technical Parameter Of Reaction-Bonded SiC Products |
| Item | Unit | Data |
| application temperature | °C | 1380 |
| density | g/cm3 | ≥3.02 |
| open porosity | % | ≤0.1 |
| bending strength | Mpa | 250(20°C) |
| Mpa | 280(1200°C) |
| modulus of elasticity | GPa | 330(20°C) |
| GPa | 300(1200°C) |
| thermal conductivity | W/(m·k) | 45(1200°C) |
| coefficient of thermal expansion | K-1×10-4 | 4.5 |
| rigidity | | 9 |
| acid & alkali resistance | | excellent |
