PBAT Dryer machine, plastic dehumidifying dryer,dehumidify dryer
supplier
What Can We Do For You ?
Infrared drying technology offers the ability to dry and
crystallize materials in minutes, compared to hours with
conventional drying equipment which reduces change over times
significantly and reduces energy consumption at almost 45%, Also Infrared drying technology changes in moisture at beginning
will dry pellets gently to a uniform degree within minutes, the final moisture can be about 50ppm
- Crystallization and drying in one process step
- Reduction of dwell time to approximately 15-20minutes
- About 40 % energy savings compared to conventional processes
- Excellent mixing properties of the material during crystallization
by adapted drum design, flexible temperature ramps and modular
machine concept
- Capacities from 100 kg/h to 1000kg/h economically feasible
- Adopt Drum rotation will make sure the constant movement of the raw
material to avoid clumping/sticking and dry evenly
- Cooling the pellets to 40°C (Re-cooling the pellets to avoid the pellets re-moistured
HOW TO WORK
1. Material Feeding 2. Rotary Drying and Crystallization 3.
Discharging
Application
Heating.Heating granules and regrind material prior to further processing
(e.g. PVC, PE, PP,…) inter alia to improve the throughput in the
extrusion.
Crystallization.Crystallisation of PET (Bottleflakes, granules, flakes), PET
masterbatch, CO-PET, PBT, PEEK, PLA,PBAT, PPS, etc.
Drying.Drying of plastic granules, and –ground material (e.g. PET, PBT,
ABS/PC, HDPE, LCP, PC, PP, PVB, WPC, TPE, TPU) as well as other
free-flowing bulk materials.
Coating.Coating of adhesives (e.g. Hot melt, EVA+lime,…)
High input moisture.Drying processes with high input moisture >1%.
Diverse.Thermal processes for the removal of rest oligomeren and volatile
components.
Machine Model
| Model Number | IRD-80 | IRD-200 | IRD-300 | IRD-500 | IRD-1000 |
Output/Capacity KG/H | 80-120 | 200 | 300 | 500 | 800-1000 |
Installation Heating power KW | 18 | 27 | 36 | 48 | 90 |
| Drying time | Normally 20mins And the drying time can be adjustable by PLC on customer’s
requirement on final moisture |
| Control | By Siemens Touch Screen PLC system |
| Processing | Dehumidifier and crystallized at a time |
| Final moisture | 30-70ppm |
| Heating way | Infrared lamps |
| Energy saving | Up to 45% |
| Space saving | Up to 300% |
| Operation | Faster to start up |
| Quick change-over and shutdown time |
Our Advantage
| Infrared Crystal Dryer
| Conventional Crystallizer |
| 1 | Easy to clean The drum can be opened completely,no hidden spots and can be
cleaned easily with a vacuum cleaner | Have to be completely disassembled,cleaned and fixed |
| 2 | Rotary drying system, its rotating speed can be increased as high
as possible to get an excellent mixing of pellets. It is good in
agitation, the masterbatch will not be clumped | Poor agitation,easy to be clumped |
| 3 | Can satisfy different type of Masterbatch (Drying temperature and
time can be adjustable by the property of raw material) | The drying temperature is fixed |
| 4 | Crystallization time 15-20mins depends on the material kind | Need 4-6 hours or more |
| 5 | Save about 40% energy consumption compared to conventional
dehumidifier
|
WORKING VIDEO OF INFRARED ROTARY DRYER
Contact Us
HOW TO ENSURE THE QUALITY!
● In order to ensure the accuracy of each part, we are equipped
with a variety of professional processing equipment and we have
accumulated professional processing methods over the past years.
● Each component before assembly needs strictly control by
inspecting personnel.
● Each assembly is in charged by a master who has working
experience for more than 20 years
●After all the equipment are completed, we will connect all the
machines and run the full production line to ensure the stable
running in customers' factory
Our Service
1. We will provide testing if the customer comes to visit factory
to see the machine.
2. We will provide detail machine technical specification ,electric
diagram,installation,operation manual and all the documents which
customer needed for clearing customs and using the machine.
3. We will provide engineers for helping installation and training
the workers at customer's site.
4. Spare parts are available when they are needed .Within warranty
time,we we will provide spare parts free,and over warranty time,we
will provide spare parts with factory price.
5. We will provide technical support and repair service in the
whole lifetime .
