Material Properties: | 95% Alumina | 99% Alumina | Zirconia | Silicon carbide | Silicon nitride | Aluminum nitride | Machinable ceramic |
| Colour | white | Light yellow | white | black | black | gray | white |
| Density (g/cm3) | 3.7g/cm3 | 3.9g/cm3 | 6.02g/cm3 | 3.2g/cm3 | 3.25g/cm3 | 3.2g/cm3 | 2.48g/cm3 |
| Water Absorption | 0 % | 0 % | 0 % | 0 % | 0 % | 0 % | 0 % |
| Hardness(HV) | 23.7 | 23.7 | 16.5 | 33 | 20 | - | - |
| Flexural Strength(MPa) | 300MPa | 400MPa | 1100MPa | 450MPa | 800MPa | 310MPa | 91MPa |
| Compressive Strength(MPa) | 2500MPa | 2800MPa | 3600MPa | 2000MPa | 2600MPa | - | 340MPa |
| Young's Modulus Of Elasticity | 300GPa | 300GPa | 320GPa | 450GPa | 290GPa | 310~350GPa | 65GPa |
| Poisson's Ratio | 0.23 | 0.23 | 0.25 | 0.14 | 0.24 | 0.24 | 0.29 |
| Thermal Conductivity | 20W/m°C | 32W/m°C | 3W/m°C | 50W/m°C | 25W/m°C | 150W/m°C | 1.46W/m°C |
| Dielectric Strength | 14KV/mm | 14KV/mm | 14KV/mm | 14KV/mm | 14KV/mm | 14KV/mm | 14KV/mm |
| Volume Resistivity(25ºC) | >1014Ω·cm | >1014Ω·cm | >1014Ω·cm | >105Ω·cm | >1014Ω·cm | >1014Ω·cm | >1014Ω·cm |
This data is typical for laboratory testing and the actual
characteristics of a particular production batch may vary.
Machining Accuracy(1) Axis: roundness 0.002 mm, concentricity 0.002 mm, smoothness
Ra0.1;
(2) Hole: the minimum processing hole diameter is 0.2 mm and the
depth is up to 6 mm (depending on the material);
(3) Slot (seam): a minimum of 0.1 mm narrow groove, and grooves of
various shapes;
(4) Plane: 0.1MM sheet with minimum processable thickness,
parallelism 0.001mm, measurement tolerance 0.001 mm, finish Ra0.1;
(5) Thread: The minimum Machinable M2 internal thread, the accuracy
of GB-7h, the external thread size is not limited, the accuracy is
GB-6g.
Delivery:
Custom OEM will be shipped within 15 days after determining the
parameters
The samples will be shipped within 3 days
Quick Delivery Via Fedex,DHL,UPS,TNT Etc.
Support customer to designate shipping company
CEO: Admin deng
Dongguan Mingrui Ceramic Tech. Co. Ltd.
Add: No.21 Chuangxing Rd., 2nd Industrial Zone of Shangsha,
Chang'an town, Dongguan city, Guangdong, China 523867
FAQ
1. Monthly Capacity: 50,000-60,000 pcs;
2. Material: OEM or as per your suggestion;
3. Lead time: about 7-20 days, pls confirm the quantities required;
4. Incoterm: FOB, CFR, CIF;
5. Delivery Cost: It is determinated by the destination port;
6. Payment Term: PayPal; T/T; L/C.
7. Shipment: by sea, by air, by courier, by post, etc.
