Custom Alumina ceramic perforated suction plate non-porous sucking
plates
Semiconductor ceramics have semiconductor properties, electrical
conductivity about 10-6 ~ 105S/m ceramics. Electrical conductivity
of the semiconductor ceramics by external conditions (temperature,
light, electric field, atmosphere and temperature, etc.) changes
and significant changes, so the external environment of the
physical quantities can be change into electrical signal, sensor
made from a variety of purposes.
Product Description
Advantages of ceramic car battery heater plate:
1. Refractory.
2. Long Service Life.
3. Good Polished Surface.
4. Environmental and Healthy.
5. Superior Mechanical Strength.
6. High Corrosion and Wear Resistance.
7. Good Insulation Performance Precision.
8. High Temperature and Pressure Resistance.
9. High Purity Zirconia and Alumina Ceramic Material.
- High hardness, long service life, not easy to break and wear
resistance.
- Non-conductive, anti-static, ceramic material itself with the
insulation of electricity and magnetism properties.
- Corrosion resistance, high temperature resistance, can be applied
to a specific environment, such as acid and alkali resistance.
Properties Sheet:
| Properties | Units | 95 Alumina | 99 Alumina | Zirconia |
| Density | ɡ / cm3 | 3.65 | 3.92 | 5.95 - 6.0 |
| Water Absorption | ％ | 0 | 0 | 0 |
| Coefficient of Thermal Expansion | 10-6 / K | 7.9 | 8.5 | 10.5 |
| Modulus of Elasticity Young’s Mod | Gpa | 280 | 340 | 210 |
| Poisson’s Ratio | / | 0.21 | 0.22 | 0.3 |
| HV Hardness | Mpa | 1400 | 1650 | 1300 - 1365 |
| Flexural Strength @ Room Temperature | Mpa | 280 | 310 | 950 |
| Flexural Strength @ 700℃ | Mpa | 220 | 230 | 210 |
| Compressive Strength@Room Temperature | Mpa | 2000 | 2200 | 2000 |
| Fracture Toughness | Mpa * m½ | 3.8 | 4.2 | 10 |
| Heat Conductivity @ Room Temperature | W / m * k | 18 - 25 | 26 - 30 | 2.0 - 2.2 |
| Electrical Resistivity @ Room Temperature | Ω*mm2 / m | ＞1015 | ＞1016 | ＞1015 |
| Max Application Temperature | ℃ | 1500 | 1750 | 1050 |
| Resistance to Acid Alkaline | / | High | High | High |
| Dielectric Constant | / | 9.5 | 9.8 | 26 |
| Dielectric Strength | KV / mm | 16 | 22 | / |
| Thermal Shock Resistance | Δ T ( ℃ ) | 220 | 180 - 200 | 282 - 350 |
| Tensile Strength @ 25℃ | Mpa | 200 | 248 | 252 |
Our wear resistance alumina Ceramic Plate Characters of Bellows:
-- Excellent wear resistance and long working life.
-- Good impact resistance.
-- Good corrosion resistantce.
-- Good thermal shock resistance.
-- Smooth surface and good adherence resistance.
-- Quick installation and good service after sale.
Application:
-As wear-resisting lining of coal-electing equipment on coal
industry
-Cements industries;
-As lining of fall funnel, lining of wear-resisting pipe and
bender,
-As lining of material tranfer pipe and chute, etc, on steel
industry.
-Material thansfer equipment;
-Inside and outside surface of powder separating equipment on iron
and steel works;
-Ceramics, mines and other grinding equipment lining;
-Parts of equipment hermal and power plants;
Detailed Images
Related Products
95% Alumina Ceramic Parts Electrical Insulator Piece / Bushing /
Tube For Different Electrical
Alumina Ceramic Cylinder Sleeve 99% Al2O3 Ceramic Transformer
Bushing Parts
View More Products
Packaging and Shipping
Ceramic plate al2o3 will be packed in a bubble bag individually,
then separated by a foam, finally put in standard export carton
packing, or OEM packing.
Shipped by Express ( DHL, TNT, UPS, Fedex, EMS ), Air, or Sea transportation.
Company information
Who Are We?
Mingrui has professional OEM experience in manufacturing industrial ceramic parts for so many
years. We can make the products according to your drawings, custom the size,
thickness and other parameters.
.
What Do We Do?
We have very advanced technologies in the production of zirconia and alumina ceramic nozzle, rod, ring, tube, shaft, plate,
sleeve, valve, plunger, bearing, and semiconductive ceramics etc.. They are applicable to Electrical, Appliance, Mining, Oil & Gas,
Energy & Power, Food & Medical, Agriculture, Aerospace,
even other High-end fields.
.
Our products with some certificates, such as , CE, TUV, etc..
Factory Show
Production Process Show
One-stop production, from the raw material ( powder ) to final
products, control the quality strickly of every production link.
