Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding

    Buy cheap Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding from wholesalers

    Buy cheap Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding from wholesalers
    • Buy cheap Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding from wholesalers

    Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding

    Ask Lasest Price
    Brand Name : Rise laser
    Model Number : RL-R1512
    Certification : ISO, ce
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100 units/ month
    Delivery Time : 5-9 working days
    • Product Details
    • Company Profile

    Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding

    Automatic Fiber Laser Welding Robot Machine with 6 Axis Cobot Robot for 10KG Payload Industrial Robot Welding

    Six-axis Robotic Arm Fiber Laser Welding Machine enables fast welding speeds, increasing efficiency and output. This can lead to faster manufacturing times and lower costs for enterprises. The performance of the six-axis industrial robot is stable, the robot’s stable performance is achieved through its precise control system, which ensures that the robot moves accurately and consistently during operation.


    Parameters

    Model
    RL-R1512
    Number of axes
    6 axis
    Radius of motion
    1550mm
    Payload
    10KG
    Degree of protection
    J1, J2 axis IP56 (J3, J4, J5, J6 axis IP67)
    Installation method
    Floor, wall-mounted, tilted, upside-down
    Battery capacity
    4.5KVA
    Input/output signal
    Standard 16 in/16 out 24VDC
    Robot weight
    172KG
    Repeatability
    +0.05
    Range of motion
    1 axis S
    ±160°
    2 axis L
    +80 to -145°
    3 axis U
    +145° to -75°
    4 axis R
    +190°
    5 axis B
    +50 to -210°
    6 axis T
    ±360°
    Movement speed
    1 axis S
    257°/s
    2 axis L
    223°/s
    3 axis U
    223°/s
    4 axis R
    392°/s
    5 axis B
    275°/s
    6 axis T
    540°/s
    Application field
    Loading and unloading, spraying, handling, packaging, cutting
    4 axis R(N.m)
    103.5
    5 axis S(N.m)
    51.84
    6 axis T(N.m)
    32.64
    Built-in trachea
    Φ10
    Installation environment
    Temperature 0-45°C,Humidity 20~80%RH (no condensation) vibration acceleration below 4.9m/S (0.5G) altitude below 1000m
    Other non-flammable, corrosive gases, liquids, no splashing water, less oil, dust away from electromagnetic sources and away from
    magnetic fields


    FQA

    1.How long is the warranty period?

    Whole machine warranty period is 1 year, laser source 2 years. If there is any problem during the period, we will solve it as soon as possible. 2.How long is the cable?

    Different laser source have different option. For example, the normal cable length of raycus and max is about 9 meters.

    3.How thick can 1500w-3000W be welded

    1-8mm thick metal materials.

    4.Is there a wire feeder?

    We have a wire feeder to choose from. If you are interested, you can contact us and provide your email address.We will send more detailed pictures to your email.

    5.Can aluminum and galvanized steel be welded?

    Yes, it can.

    6.Packaging

    All our machines are packed in wooden boxes.

    7.Language interface

    Supports language customization, etc. You can also translate and insert to software.
