    Lithium Battery Fire Thermal Insulation Pads Non Combustible Aerogel Felt

    Ask Lasest Price
    Brand Name : FQ
    Model Number : Aerogels 01
    Certification : IATF16949
    Price : Fuzhou Fuqiang Precision Co.,Ltd.
    Payment Terms : L/C, T/T, D/P
    Supply Ability : 1000pcs/day
    Delivery Time : 1000 pcs/ days
    • Product Details
    • Company Profile

    Lithium Battery Fire Thermal Insulation Pads Non Combustible Aerogel Felt

    Battery Thermal Management System Aerogel Insulation Ceramic Fiber Aerogel Felt flame retardancy

    Main Features

    Our cutting-edge Battery Thermal Management System (BTMS) offers superior thermal insulation for electric vehicle batteries, thanks to our innovative Aerogel Insulation and Ceramic Fiber Aerogel Felt materials.

    Our Aerogel Insulation material is made from a highly efficient and lightweight nano-insulation material with extremely low thermal conductivity, ensuring that your EV's battery stays at the optimal temperature for maximum efficiency and lifespan. Additionally, our Ceramic Fiber Aerogel Felt material provides added flame retardancy, ensuring the safety of your electric vehicle.

    Upgrade your electric vehicle with our BTMS and experience the benefits of superior thermal insulation and added safety for your EV battery. Trust us to provide you with the best quality materials and expert installation, for an improved and long-lasting performance of your electric vehicle's battery.

    For more information on our BTMS or to place an order, please don't hesitate to contact us. Our team is ready to help you take your electric vehicle to the next level.


    SNPerformanceperformance requirements
    1Quality deviation rateShould not be greater than 15%.
    2Thermal insulation performanceThe shrinkage rate of the length and width of the sample before and after the test should not be greater than 3%, and the test process should be within 5 minutes
    The temperature of the cold side of the sample should not exceed 180°C.
    3vertical burnIt should meet the V0 requirements specified in GB/T 2408.
    4Compression ratioIt should not be less than 35% under 2Mpa pressure.
    5tensile strengthThe length and width direction should not be less than 500Kpa.
    6Insulation propertiesSurface thermal resistivity should be greater than 500MΩ; leakage rate should be less than 1mA.
    7Prohibited and restricted substancesShould comply with Directive 2011/65/EU.
    8Aging resistanceAfter aging, the tensile strength attenuation rate of the airgel heat insulation sheet should not exceed 30%;
    The dimensional change rate should be less than 1%; the heat insulation performance should meet the requirements in the table.
    Specification

    The main performance parameters are shown in Table

    Product numberPysheild BP-PAN
    thickness1~10mm
    wide1400±60mm(Customized)
    colorBlack
    Maximum operating temperature800℃(anaerobic)
    density200±20kg/m3
    Thermal Conductivity≤0.025W/m*K@25℃GB/T 10295-2008
    ≤0.030W/m*K@100℃GB/T 10294-2008
    ≤0.036W/m*K@300℃
    ≤0.072W/m*K@500℃
    Combustion levelA GradeGB/T 8624-2012
    V0UL94-2013
    Hydrophobicity＞98%GB/T10299-2011
    biosecurityComply with biosafety requirementsRoHs/REACH/ELV
    Burn-through resistance＞0.3MPaASTM C273
    Insulation effect1mm:Min≥385℃；2mm:Min≥440℃

    3mm:Min≥495℃；4mm:Min≥520℃
    Application field
    New energy passenger car batteries and modules are used for heat insulation, buffering, flame retardant, thermal runaway protection, etc.

    Typical Applications

    The functions of heat insulation, buffering, flame retardancy, thermal runaway protection and other functions of new energy passenger vehicle cells and modules
